For situations where you might want or need to
change the settings, see the descriptions of each set-
ting in the user’s guide. If you need to change any of
the default settings, or if you would like to format or
verify a disk, see Starting the SCSISelect Utility on
page 9 to start the utility.
1
Applies to AHA-2940 only
2
Applies to AHA-2940W only
3
Setting is valid only if Multiple LUN Support is enabled
4
Settings are valid only if host adapter BIOS is enabled.
Basic Host Adapter Settings Default
Host Adapter SCSI ID 7
SCSI Parity Checking Enabled
Host Adapter SCSI Termination Automatic
1
;
Low ON/
High ON
2
Boot Device Settings Default
Boot Target ID 0
Boot LUN Number
3
0
SCSI Device Settings Default
Initiate Sync Negotiation Yes (Enabled)
Maximum Sync Transfer Rate 10 MBytes/sec
Enable Disconnection Yes (Enabled)
Initiate Wide Negotiation
2
Yes (Enabled)
Send Start Unit SCSI Command
4
No (Disabled)
Advanced Host Adapter Settings Default
Plug and Play SCAM Support Disabled
Host Adapter BIOS Enabled
Support Removable Disks Under BIOS as Fixed Disks
4
Boot only
Extended BIOS Translation for DOS Drives > 1 GByte
4
Enabled
Display <Ctrl-A> Message During BIOS Initialization
4
Enabled
Multiple LUN Support
4
Disabled
BIOS Support for More Than 2 Drives
4
Enabled
BIOS Support for Bootable CD-ROM
4
Enabled
BIOS Support for Int 13 Extensions
4
Enabled
