SERIES 5 DATA SHEET
Adaptec SATA & SAS RAID Family (5405, 5445, 5805, 5085, 51245, 51645, 52445)
PMC-Sierra, Inc.
1380 Bordeaux Dr.
Sunnyvale, CA 94089 USA
Tel: +1 (408) 239-8000
© Copyright PMC-Sierra, Inc. 2011. All rights reserved. PMC, PMC-SIERRA and Adaptec are registered trademarks of PMC-Sierra, Inc. “Adaptec by PMC” is a trademark of PMC-Sierra, Inc.
Other product and company names mentioned herein may be trademarks of their respective owners. For a complete list of PMC-Sierra trademarks, see www.pmc-sierra.com/legal.
DS_Series5_062411_US Information subject to change without notice.
World Wide Web: www.adaptec.com
Pre-Sales Support: US and Canada: 1 (800) 442-7274 or (408) 957-7274 or adaptecsales@pmc-sierra.com
UK: +44 1276 854 528 or uk_sales@pmc-sierra.com
Australia: +61-2-95031555
Singapore: +65-92351044
Adaptec Unified Serial Controller Family
Why to buy? Performance Unified Serial RAID controllers support both SATA and SAS devices. Ideal for bandwidth intensive storage applications;
NAS, online transaction processing servers (OLTP), web servers, digital surveillance and stream applications.
Customer Needs High I/O transaction and high bandwidth processing
Intelligent Power Management Automated customer-configurable feature that reduces disk drive energy use by up to 70% without compromising application
performance. Two configurable modes supported:
Standby mode – low-power mode; drive rotates at reduced RPM when not in use (requires that the drive support Advanced Power
Management specification). See Adaptec compatibility report for a list of supported disk drives.
Power-off mode – Spin down drives when not in use.
RAID Features — Supports up to 256 SATA or SAS devices using SAS expanders
— RAID levels 0, 1, 1E, 5, 5EE, 6, 10, 50, 60 and JBOD
— Quick initialization
— Online Capacity Expansion
— Copyback Hot Spare
— Dynamic caching algorithm
— Native Command Queuing (NCQ)
— Background initialization
— Hot-plug drive support
— RAID Level Migration
— Hot spares - global, dedicated, and pooled
— Automatic/manual rebuild of hot spares
— SAF-TE enclosure management
— Configurable stripe size
— S.M.A.R.T. support
— Multiple arrays per disk drive
— Dynamic sector repair
— Staggered drive spin-up
— Bootable array support
— Optimized Disk Utilization
Management Utilities Adaptec Storage Manager™ (ASM)
— Java-based GUI Management Utility
— Remote configuration, monitoring and notification
— ASM OS Support: Windows, Linux, SCO, Solaris,
— Microsoft VDS Support
— SNMP, SMTP
— Remote firmware updates
ARCCONF
— Command Line Interface
Adaptec BIOS Configuration Utility (ACU)
— BIOS level configuration utility
— Flashable BIOS support
Operating System Windows 7, Windows XP, Server 2003/2008, Vista, Red Hat Enterprise Linux (RHEL), SUSE Linux Enterprise Server (SLES),
SCO OpenServer, UnixWare, Sun Solaris 10 x86, FreeBSD
Physical Dimensions 5085/5405/5445/5805 — 2.5”H x 6.6”L (167mm x 64mm) 51245/51645/52445 — 4.6”H x 6.43”L (164mm x 116mm)
Operating Temperature* 0°C to 55°C (with 200 LFM airflow; without battery)
0°C to 40°C (with 200 LFM airflow; with battery)
0°C to 55°C (with 200 LFM airflow; without battery)
0°C to 40°C (with 200 LFM airflow; with battery)
Operating Voltage 0.45A @ 3.3V; 1A @ 12V 0.47A @ 3.3V; 1.8A @ 12V
Regulatory Certification CE, FCC, UL, C-tick, VCCI
MTBF 873,402 hours at 40°C
Warranty 3 years
Accessories Adaptec Battery Module 800 (2248000-R), Adaptec Battery Module 800T (2263800-R)
Adaptec RAID 5405 5445 5805 5085 51245 51645 52445
Order Part Number 2258100-R (kit)
2258200-R (single)
2228800-R (kit)
2244900-R (single)
2244100-R (kit)
2244300-R (single)
2249100-R (single) 2268200-R (kit)
2268100-R (single)
2258500-R (kit)
2258600-R (single)
2258800-R (kit)
2258700-R (single)
Form Factor MD2 - Low Profile MD2 - Low Profile MD2 - Low Profile MD2 - Low Profile Half Length/
Full Height
Half Length/
Full Height
Half Length/
Full Height
Ports 4 internal 8 (4 int./4 ext.) 8 internal 8 external 16 (12 int./4 ext.) 20 (16 int./4 ext.) 28 (24 int./4 ext.)
Connectors 1 SFF-8087 (int.) 1 SFF-8087 (int.)
1 SFF-8088 (ext.)
2 SFF-8087 (int.) 2 SFF-8088 (ext.) 3 SFF-8087 (int.)
1 SFF-8088 (ext.)
4 SFF-8087 (int.)
1 SFF-8088 (ext.)
6 SFF-8087 (int.)
1 SFF-8088 (ext.)
Bus Interface 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1 8-Lane PCIe Gen1.1
Processor 1.2 GHz Dual Core 1.2 GHz Dual Core 1.2 GHz Dual Core 1.2 GHz Dual Core 1.2 GHz Dual Core 1.2 GHz Dual Core 1.2 GHz Dual Core
Cache 256MB 512MB 512MB 512MB 512MB 512MB 512MB
Fanout Cable/s
(kit only)
mSASx4 to 4xSATA
w/sideband (0.5M) x1
mSASx4 to 4xSATA
w/sideband (0.5M) x1
mSASx4 to 4xSATA
w/sideband (0.5M) x2
None
(Single only)
mSASx4 to 4xSATA
w/sideband (0.5M) x3
mSASx4 to 4xSATA
w/sideband (0.5M) x4
mSASx4 to 4xSATA
w/sideband (0.5M) x6
™
*Note: This Adaptec card contains a powerful RAID processor which requires adequate airflow to operate reliably. Please install this card only into server or PC chassis with recommended airflow (200 LFM).
Ambient temperature measured 1” away from the RAID processor.
