ADB P.DG A4001N User Manual

Home Station ADSL ADB P.DG A4001N
© (2011) ADB Broadband S.p.A. All Rights Reserved. Proprietary Use Pursuant to Cover Page Instructions.
58 Advanced Setup Section
FIGURE 24. Default Gateway Panel
ROUTING >> STATIC ROUTE
The Static Route screen can be used to add a routing table (a maximum of 32
entries
can be configured). Click on Add button to add a static route and, at the end of pa-
rameters’ configuration, press the Apply/Save button.
The Remove button, upon a route selection, will delete existing static routes.
TABLE 3. Static Route Parameters
Parameter Description Example
Destination Destination Network address 20.0.0.0
Subnet Mask Subnet mask 255.255.255.0
Gateway Gateway IP address
Interface Available WAN interfaces br0
