GENERAL ARRANGEMENT (PETROL MODEL)
I. Inspection Plug 8. On/Off Switch 14. Pressure Gauge
2. Air Receiver 9. Solenoid Valve 15. Non-return Valve
3. Oil Filler/Breather 10. Wire Guard & Automatic Pressure Controller
4. Exhaust (Motor) 11. Air Delivery Pipe 16. Safety Valve
5. Air Filter (Motor) 12. Air Compressor Pump 17. Oil Level Sight Glass
6. Petrol Motor 13. Air Intake Filter 18. Oil Drain Plug
7. Pull Start Recoil 19. Drain Tap
Note: Illustrations are for reference only. Certain models may differ.
Periodic maintenance and adjustment is necessary to keep the compressor engine in good operating
condition. Perform the service and inspection at the intervals shown in the Maintenance Schedule on
page 13:
KEY
1. Service more frequently when used in dusty areas.
2. These items should be serviced by an authorised compressor dealer.
3. For professional use, log hours of operation to determine proper
maintenance intervals.
Figure 6
