13 C-21 BIKE
WWW.ADIDASHARDWARE.COM 14
SERIAL NUMBER
Serial Number is located on the base of the
machine e.g. Serial No.:AVUS-10401/0718/000001
Serial No.
MACHINE WEIGHT
= 41KG/90.4LB
MAX USER WEIGHT
= 150KG/330.7LB
41KG
150KG
PARTS LIST
NO. PART DESCRIPTION QTY
1 Console 1
2 Screw M5*10L 10
3 Console plate 1
4 Upper console cover 1
5 End cap 2
6 Seat 1
7 Sliding seat 1
8 Slider fixed bolt 1
9 Upper slider cover 1
10 Seat post 1
11 Knob 1
12 Lower slider cover 1
13 Screw M5*16L 6
14 Screw M5*10 1
15 Water bottle holder 1
16 Main cover (R) 1
17 Light straps 2
18 170 Crank (R) 1
19 Right Pedal 1
20 Crank cover 2
21 Nut 2
22 Light PCB 1
23 Plastic insert 2
24 Screw ST3.9*16L 4
25 Belt 450J6 1
26 Axle 1
27 Hex screw M6*P1.0*16L 4
28 Nylon nut M6*5.5T 4
29 Spring washer Ø6.1*1.6T 4
30 Magnetic sets 1
31 Hex screw M8*55L*S25L 1
32 Flat washer Ø8*Ø19*2T 1
33 Nylon nut M8 1
34 Spring 1
35 Idler shaft 1
36 Hex screw M8*20L 1
37 Idler spring 1
NO. PART DESCRIPTION QTY
38 Wave washer Ø10.2*Ø13*0.3T 1
39 Bearing 6000 2ZZ 2
40 Idler wheel 1
41 Flat washer Ø6*Ø14*1T 1
42 Screw M6*10L 1
43 Plastic washer 1
44 Nut 3/8"-26*7T 2
45 Hex nut 3/8"-26*4.5T 2
46 Wave washer Ø12.5*Ø18*1.5T 1
47 C shape clasp Ø12 3
48 Front Stabilizer 1
49 Bearing 6901 1
50 Flywheel Ø280*32W 7KG 1
51 Bearing 6001 1
52 Self-generating sets 1
53 Rear stabilizer end cap 2
54 Screw ST4.8*1.4*20L 8
55 Rear stabilizer 1
56 Screw M8*P1.25*50L*S25L 4
57 Nylon Nut M8 1
58 Flat washer Ø8*Ø19*2T 11
59 Front stabilizer cover 1
60 Rear stabilizer cover 1
61 Frame 1
62 Motor 1
63 Flat washer Ø5.5*Ø12*2T 2
64 Hex screw M5*P0.8*12L 2
65 Pulley 1
66 Bearing 6004 2RS 2
67 Sleeve 1
68 Seat post cover 1
69 Knob with pulling pin 1
70 Wave washer Ø20.5*Ø30*0.3T 1
71 C shape clasp Ø18.5*Ø22.5*1T 2
72 Flat washer Ø20.3*Ø30*0.5T 1
73 Sensor 1
74 Control board 1
NO. PART DESCRIPTION QTY
75 Sensor bracket 1
76 Left Pedal 1
77 Upright 1
78 Screw M8*P1.25*20L 5
79 Spring washer Ø8.0*2.5T 15
80 Semicircle washer Ø8*Ø19*2T 5
81 Upper cable 1
82 Lower cable 1
83 Hex screw M8*P1.25*20L 6
84 Upright cover 1
85 Batteries box holder 1
86 AA Battery 7
87 Batteries box cover 1
88 Screw ST3.5*16L 1
89 Lower cover of console 1
90 Screw ST2.9*30L 2
91 Screw ST2.9*16L 2
92 Handlebar 1
93 Pulse grip 2
94 Screw ST2.9*20L 4
95 Pulse wire 2
96 Front stabilizer end cap R 1
97 Front stabilizer end cap L 1
98 Screw ST3.9*50L 6
99 Main cover (L) 1
100 Crank (L) 1
101 Harpoon wrench 13.15.17 1
102 Socket wrench 13.14 1
103 Hex wrench 6mm*35mm*115mm 1
104 Battery connected wire 1
105 MCB connected wire 1
106 Light connected wire 1
107 Screw M5*12L 2
108 End Cap 2
109 Screw M3* 10L 2
110 Magnetic ring Ø31*Ø19*13 2
