17 X-21 CROSSTRAINER
WWW.ADIDASHARDWARE.COM 18
1 Console 1
2 Button Cover 2
3 Hand grip lower cover 2
4 Hand grip Button(+) 1
5 Hand grip Spring 2
6 Hand grip PCB 2
7 Hand grip upper cover 2
8 Hand grip Wire(+) 1
9 Screw ST2.9*20L 4
10 Screw M5*14L 4
11 Screw ST2.9*10L 2
12 Hand grip Button(-) 1
13 Lower console cover 1
14 Screw M5*14L 8
15 Screw ST2.9*30L 2
16 Screw ST2.9*20L 4
17 Screw ST3.5*12L 1
18 Batteries box holder 1
19 Screw M5*8L 2
20 Batteries box cover 1
21 AA Batteries 7
22 Handlebar 1
23 Hand grip Wire(-) 1
24 Screw M8*P1.25*16L 3
25 Spring washer Ø8.5*Ø13.5*2.5T 17
26 Flat washer Ø8*Ø19*2T 15
27 Semicircle washer Ø8*Ø19*2T 5
28 Centre shaft cover 2
29 Upper console cover 1
30 Water bottle holder 1
31 Upright 1
32 Upright Cover 1
33 Screw M8*P1.25*20L 6
34 Screw M8*P1.25*55L*S10 1
35 Nut M8*7T 7
36 Magnetic sets 1
37 Spring Ø1*Ø8.5*48L 1
38 Motor bracket 1
39 Screw M5*10L(Ø9.5) 2
40 Control board 1
41 Screw M10*48L*S15L 1
42 6mm bushing 1
43 Idler wheel 1
44 9mm bushing 1
45 Nut M10*9T 1
46 Ø20 Washer 2
47 Flat washer Ø20.3*Ø30*0.5T 1
48 Wave washer Ø20.5*Ø30*0.3T 1
49 Bearing 6004 2RS 2
50 Sensor bracket 1
51 Motor sets 1
52 Flat washer Ø5.5*Ø12*2T 2
53 Screw M5*P0.8*12L 2
54 Nylon Nut M6*5.5T 4
55 Spring washer Ø6.1*1.6T 4
56 Toroidal cores 1
57 Pulley 1
58 Axle 1
59 Screw M6*P1.0*16L 4
60 Belt 500J6 1
61 Screw ST3.9*16L 8
62 Flat washer Ø4.5*Ø16*1.5T 8
63 Cross-brace 2
64 Upper /Lower Cover 1
65 Plastic insert 5
66 Screw ST4.2*16L 8
67 Lights 2
68 Lights connected wire 2
69 Lights PCB 1
70 Disc 2
71 Nut M10*P1.25*10T 2
72 Disc cover 2
73 Screw M5*12L 20
Left Pedal tube Cover 2
74 R Right Pedal tube Cover 2
75 Screw M8*78L*S20L 2
Left pedal 1
76R Right pedal 1
77 Screw M8*50L*S20L 4
Left pedal tube 1
78R Right pedal tube 1
79 30*60 Cap 4
80 Ø48 Cap 2
81 C-shape clasp Ø40 2
82 Bearing 2203 2RS 2
83 Flat washer Ø8*Ø22*2T 4
84 Screw M8*P1.25*20L 4
85 Screw ST3.9*50L 6
86 Pedal Cap 2
87 Screw ST4.8*12L 8
88 Front Stabilizer end cap(L) 1
89 Front Stabilizer 1
90 Front Stabilizer Cover 1
91 Screw M8*P1.25*50L 4
92 Front Stabilizer end cap(R) 1
93 Rear Stabilizer end cap 2
94 Rear Stabilizer Cover 1
95 Rear Stabilizer 1
96 Bearing 6000 2
97 Frame 1
98 Nut 3/8"-26*7T 2
99 Nut 3/8"-26*4.5T 2
100 Self-generating sets 1
101 C-shape clasp Ø20 7
102 Flat washer Ø12.2*Ø18*0.5T 1
103 Bearing 6001 2RS 5
104 Flywheel 1
105 Bearing 6901 2RS 1
106 Flat washer Ø12*Ø16*1T 1
107 Wave washer Ø12.3*Ø15.3*0.3T 1
108 Upper Handlebar grip(L) 1
109 Screw ST4.8*16L 2
110 Grip cover 2
Upper Handlebar(Left) 1
111R Upper Handlebar(Right) 1
112 Front cover of upper handlebar 2
113 Insert M8*20L 6
114 Screw M8*20L 6
115 Bearing 6003 2ZZ 4
116 Wave washer Ø17.5*Ø25*0.3T 2
117 Rear cover of upper handlebar 2
118 Lower Handlebar 2
119 Joint bushing 2
120 Upper Handlebar grip(R) 1
121 Upper cable 1
122 Lower cable 1
123 Lights connected wire 2
124 DC wire 1
125 Battery connected wire 1
126 MCB connected wire 1
127 Sensor wire 1
128 Socket wrench 13.14 2
129 Wrench 6MM 2
