6. Command Set
There are three categories of NuDAM commands. The first is
the general commands, including set configuration command,
read configuration, reset, read module‘s name or firmware
version, etc. Every NuDAM can response to the general
commands. The second is the functional commands, which
depends on functions of each module. Not every module can
execute all function commands. The third is the special
commands including functions about the programmable
watchdog timer, safe values, and the programmable leading
code. All the commands used in the NuDAM analog input
module are list in the following table.
Command
Syntax
General Command
Set Configuration
%(OldAddr)(NewAddr)
(InputRange)(BaudRate)
(DataFormat)
Read Configuration
$(Addr)2
Read Module Name
$(Addr)M
Read Firmware Version
$(Addr)F
Software Reset
$(Addr)RS
Reset Status
$(Addr)5
Functional Command
Read Digital Output Status
$(Addr)6
Digital Output
#(Addr)(ChannelNo)(OutDa
ta)
Special Command
Read Command Leading Code
Setting
~(Addr)0
Change Command Leading
Code Setting
~(Addr)10(C1)(C2)(C3)
(C4)(C5)(C6)
Set Host Watchdog / Safety
Value
~(Addr)2(Flag)
(TimeOut)(SafeValue)
Read Host WatchDog / Safe
Value
~(Addr)3
Host is OK
~**
I/O Polarity Setting
~(Addr)CP(State)
Read Polarity Setting
~(Addr)CR
* The module accepts calibration command, baud rate and
checksum configuration setting under the DEFAULT*
mode.
* Please refer the manual in PDF file format in the CD for
detail description of these commands.
