L900650A October 2003
AdobeAir, Inc., 500 S. 15th Street, Phoenix, Arizona 85034 www.AdobeAir.com
Since AdobeAir, Inc. follows a policy of continuous product improvement, we reserve the right to change specifications and design without notice.
© 2003 All rights reserved, AdobeAir, Inc.
Inside
Duct Frame
Cooler Grille
Adjustable
Duct
Drywall
2 x 4Insulation
Stucco
Cooler
Outside
Duct Frame
Stucco
Drywall
Cooler
2 x 4
Insulation
Height: 35
1
/4
Width: 42
1
/2
Depth: 13
7
/8
Amps: 6.5
Industry Standard Rating: 3000*
Installation
Specifications
* Industry Standard Rating is used in comparing units
of different manufacturers.
