TABLE 9
NATURAL GAS MANIFOLD PRESSURES − in. w.g. (kPa)
ALTITUDE – FEET (METERS)
SEP
0−2000
2001− 2500
2501 −3500
3501 − 4500
4501 − 5500
5501 − 6500
6501 − 7500
UNIT
(0−610)
(610−762)
(763−1067)
(1067−1372)
(1372−1676)
(1677−1981)
(1981−2286)
SEP−100**
3.5
3.5
3.5
3.5
3.4
3.3
3.2
SEP−115**
(0.87)
(0.87)
(0.87)
(0.87)
(0.84)
(0.82)**
(0.79)**
SEP−300
SEP−145**
3.5
3.4
3.3
3.2
3.1
3.0
2.9
(0.87)
(0.84)
(0.82)
(0.79)
(0.77)
(0.74)**
(0.72)**
SEP−175*
3.5
3.5
3.5
3.5
3.5
3.5
3.5
SEP−230
(0.87)
(0.87)
(0.87)*
(0.87)*
(0.87)*
(0.87)*
(0.87)*
SEP−200
SEP−250
3.5
3.5
3.5
3.4
3.3
3.2
3.1
SEP−345
(0.87)
(0.87)
(0.87)
(0.84)
(0.82)
(0.79)
(0.77)
SEP−400
* The SEP−175 unit requires pressure switch change when installed at elevations above 2500 feet (762m). Order pressure switch 176722600. No
adjustment to switch is required.
* SEP models −100, −115 and −145 require pressure switch change when installed at elevations above 5500 feet (1676m). Order pressure switch
176722600. No adjustment to switch is required.
TABLE 10
LP/PROPANE GAS MANIFOLD PRESSURES − in. w.g. (kPa)
ALTITUDE – FEET (METERS)
SEP
0−2000
2001− 2500
2501 −3500
3501 − 4500
4501 − 5500
5501 − 6500
6501 − 7500
UNIT
(0−610)
(610−762)
(763−1067)
(1067−1372)
(1372−1676)
(1677−1981)
(1981−2286)
SEP−100**
9.0
9.0
9.0
9.0
8.7
8.4
8.1
SEP−115**
(2.24)
(2.24)
(2.24)
(2.24)
(2.16)
(2.09)**
(2.01)**
SEP−300
SEP−145**
9.0
8.7
8.4
8.1
7.8
7.5
7.2
(2.24)
(2.16)
(2.09)
(2.01
(1.94)
(1.86)**
(1.79)**
SEP−175*
9.0
9.0
9.0
9.0
9.0
9.0
9.0
SEP−230
(2.24)
(2.24)
(2.24)*
(2.24)*
(2.24)*
(2.24)*
(2.24)*
SEP−250
9.0
9.0
9.0
8.7
8.4
8.1
7.8
(2.24)
(2.24)
(2.24)
(2.16)
(2.08)
(2.01)
(1.94)
SEP−200
9.5
9.5
9.5
9.2
8.9
8.6
8.3
SEP−345
(2.37)
(2.37)
(2.37)
(2.28)
(2.21)
(2.13)
(2.06)
SEP−400
* The SEP−175 unit requires pressure switch change when installed at elevations above 2500 feet (762m). Order pressure switch 176722600. No
adjustment to switch is required.
* SEP models −100, −115 and −145 require pressure switch change when installed at elevations above 5500 feet (1676m). Order pressure switch
176722600. No adjustment to switch is required.
