ADT Video Doorbell

Quick Installation Guide

HARDWARE

INSTALLATION

DBC835 Wireless Doorbell Camera Installation

Always On Bracket Installation

The Always On bracket can only be installed with mechanical doorbell chimes

(AC16V~24V). In this configuration, the doorbell camera will be in always on mode,

which brings back the 5 second pre-buffer, connects live view faster, and removes

the need for the internal battery to be charged.

1. Choose the mounting bracket that will cover the hole of the legacy doorbell

button. The larger bracket should be used with gang boxes.

Figure 4-11 Choosing Mounting Bracket

2. Connect the power wires from the existing doorbell to the screw terminals of

the bracket.

Figure 4-12 Connecting the power Wires
