Adtec EN-30 - PID Settings; PIDs Menu Configuration

PIDs Menu
The following diagram illustrates the structure and flow of the PIDs Menu on the Adtec
EN-30 device:
Control
Function
Options
API Command
PMT PID
Configures PID marked for
the PMT
Hex value 0x0020 -
0x1FFE
*.ECMD# PPI
PCR PID
Configures PID marked for
PCR packets
Hex value 0x0020 -
0x1FFE.
*.ECMD# PRP
Video PID
Configures PID marked for
the Video PES stream
Hex value 0x0020 -
0x1FFE
*. ECMD# VPI
Aud 1 PID
Configures PID marked for
the Audio 1 PES stream
Hex value 0x0020 -
0x1FFE
*.ECMD# API 0
Aud 2 PID
Configures PID marked for
the Audio 2 PES stream
Hex value 0x0020 -
0x1FFE
*.ECMD# API 1
Aud 3 PID
Configures PID marked for
the Audio 3 PES stream
Hex value 0x0020 -
0x1FFE
*.ECMD# API 2
Aud 4 PID
Configures PID marked for
the Audio 4 PES stream
Hex value 0x0020 -
0x1FFE
*.ECMD# API 3
Tltxt PID
Configures PID marked for
Teletext Packets
Hex value 0x0020 -
0x1FFE
*.ECMD# TPI
VITC Mode
Enables VITC Mode
OFF
ON
*.ECMD# BMO 1
VITC PID
Configures PID marked for
ANC / VITC Packets
Hex value 0x0020 -
0x1FFE
*.ECMD# BMI 1
Splice PID
Active
Enables Splice PID
OFF
ON
*.ECMD# RIT
Splice PID
Configures PID marked for
Splicing
Hex value 0x0020 -
0x1FFE
*.ECMD# SPI
Note: No two PID’s may be configured for the same value with the exception of VIDEO and
PCR. The encoder does not accept PID values already assigned to another elementary
stream. Use the PDU command to get a ‘Program Dump’ of all assigned PID’s. Adtec
Digital encoders have the ability to process VBI waveform data and Ancillary (SDI non video
information), however they can't process both at the same time. If the "VITC PID" option is
turned on, waveform closed captions and teletext will not be able to be processed.
