Figure 3. Dual LIU Menu Tree (continued)
3. Status
5. Test
6. Performance Monitoring
4. Alarms
1. T1 Loopbacks
2. T1 Monitor Select
4. LIU Reset
1. None
3. T1 B
2. T1 A
Line Buildout
Framing
LIne Code
Loopback
Inband Loopback
Loop Status
Circuit A
Bank Mode
Timing Source
1. Enable
2. Disable
Primary
Secondary
Current
1. Daily
3. Qtr-Hour
2. Far-End Daily
5. Daily Threshold
4. Far-End Qtr-Hour
6. FE Daily Threshold
8. FE Qtr-Hour Threshold
9. Reset Performance Registers
7. Qtr-Hour Threshold
10. Restore Factory Default Thresholds
12. Disable all LIU Threshold Alarms
13. Select T1
11. Enable all LIU Threshold Alarms
Circuit B
1. T1-A
2. T1-B
1. None
3. Line & Local
2. Local
5. Line
4. Payload
6. Remote Inband
A
1. CLK OOS Alarm
7. Remote Line*
8. Remote Payload*
* Not available in SF Framing.
1. T1-A
2. T1-B
