- 19 -
2
.
0 Installation of the wood burning stove
You are welcome to install your wood burning stove yourself – but we strongly recommend that you consult your
chimney sweep before you begin the installation. Your dealer can also provide you with installation advice. It is
important to ensure that all local rules and regulations, including ones relating to national and European standards,
are complied with when installing this device.
Please note: You may not begin to use the wood burning stove until it has been inspected and approved by your
local chimney sweep.
2.1 Position of the stove/distance requirements
The new wood burning stove must be installed in a suitable and physically possible position. You need to be sure
that the position complies with local regulations. Distance requirements will only apply if the wood burning stove is to
be placed close to flammable materials. The Aduro 11 should be installed at a distance of 20 cm from flammable
materials at the rear and at a distance of 30 cm from the side. All furniture must be kept at least 85 cm away from
the front of the stove. If the stove is installed with an insulated pipe then you may reduce the distance behind the
stove to 10 cm. See illustration below. The distances are measured from the top of the stove.
If the stove is positioned against a brick wall or other non-flammable material, there is no minimum distance
requirement. To facilitate cleaning and for the best use of the convection air, we recommend that you leave a
distance of approximately 5–10 cm to the wall. The Aduro 11 is built as a convection stove. This means that air from
the room circulates between the inner stove and the outer covering. As a result, the heated air is distributed evenly
throughout the room.
Behind stove
85
3030
20/10*
* When using an insulated pipe
Please note: that the Aduro 11 must be installed on a floor with the adequate load-bearing capacity. If the existing
construction does not meet this requirement, appropriate adaptation measures must be taken (e.g. a load-
distributing plate).
If the wood burning stove is to be placed close to flammable material, such as a wooden floor or carpet, it must be
placed on a non-flammable base. The floor plate should extend for at least 30 cm in front of the wood burning
stove, and 15 cm on each side.
2.2 Pipe connection
Aduro 11 leaves the factory with the flue outlet mounted on the top. If you require the flue outlet on the back,
remove the round circle from the rear cover at the upper rear of the stove. The cover plate (that covers the rear
outlet) should then be moved to the top outlet. The top outlet is finished with the plate that lies in the ash drawer. A
flue pipe with an internal diameter of 150 mm should be used for Aduro stoves.
