Good luck with your new wood burning stove!
In order to get the best possible pleasure and benefit from your new Aduro wood burning stove, it is
important that you read this User Manual thoroughly before you install your wood burning stove and start to
use it.
1.0 General
1.1 Compliance
Aduro 3 complies with the EN 13240 European standards, as well as the NS 3058 Norwegian standard and
is thereby approved for installation and use in Europe. The product documentation for Norway has Sintef
number 110-0234 and can be downloaded from our website at
www.aduro.no or from www.nbl.sintef.no. At
the same time, the manufacturing process is subject to external quality control. Aduro 3 also carries the
Nordic Swan Eco-label, which guarantees that the wood burning stove complies with the most stringent
environmental requirements and has been manufactured in an environmentally correct manner.
1.2 Technical data
Nominal power: 5 kW
Chimney draught 12 Pa
Maximum combustion amount per hour:
- Wood approx. 2.4 kg
Heat rating in buildings with:
Optimum insulation: 130 m
2
Average insulation: 90 m
2
Inadequate insulation: 50 m
2
Flue outlet, diameter: 150 mm
Weight: Aduro 3 with drawer 95 kg and Aduro 3 with wood tray 88 kg.
1.3 Transportation
When taking your wood burning stove home, please ensure that it travels in an upright position. If you wish
to lay it flat, it is important that you remove loose parts from the combustion chamber (cast iron grate and
loose fireproof tiles) and remove the ash drawer. Alternatively you could also fill the combustion chamber
with excess packaging so the parts are kept in place.
1.4 Serial number
The wood burning stove has a serial number on the rating plate on the back of the stove. Please write this
number in the space below. For the purposes of the guarantee and for other enquiries, it is important that
you are able to quote this number.
Serial number
