Advanced Air 2530 - Page 2

2530_IOM_1.1_Mar21_2
2
Page
Introduction and Health & Safety 3
Fire & Smoke damper – Model 2530
Two hour flexible wall – AFS with drop rods one side 4
Two hour flexible wall – AFS with drop rods two sides 5
Two hour flexible wall – multi-section AFS with drop rods two sides 6
Two hour rigid wall – AFS with drop rods one side 7
Two hour rigid wall – AFS with drop rods two sides 8
Two hour rigid wall – HEVAC 9
Two hour – remote from wall 10
Two hour rigid floor – AFS 11
Two hour rigid floor – HEVAC 12
Operation and Maintenance 13
Wiring information
2530 14
2530 multi-section 15
DW145 Fire Damper Certificate 16
Index
