MAINTENANCE
Before adjusting the brake, tread the
brake pedal several times to adjust
the brakes.
CAUTION
1. To change the length of the push
rod and thus increase the brake
pedal free travel, firstly loosen the
lock nut on the brake master
cylinder push rod, then carefully
turn the push rod in the
counterclockwise direction.
After adjusting the brake pedal
travel properly, tighten the screw in
time to prevent it from loosening.
2. The brake pedal free travel can be
adjusted, but not frequently. It is
recommended to adjust the
distance between 1/8 to 1/4 in and
increase the length of the push rod
by 1/2 in.
WARNING
Do not loosen the brake cables because
of air leakage, which will also affect the
brake adjustment and result in
braking function.
28
