Appendix B Motherboard Options 母板选择 主機板選擇
Table B.2: MicroATX motherboard options/MicroATX母板选择/MicroATX主
機板選擇
Model Name/
型号名称 /
型號名稱
Bus/总线/匯流排
PCI PCI/ISA ISA SATA
AIMB-581
1 (PCIe x16)
1 (PCIe x4)
2 (PCI 32-bit)
--4
AIMB-580
1 (PCIe x16)
1 (PCIe x4)
2 (PCI 32-bit)
--6
AIMB-567
1 (PCIe x16)
1 (PCIe x4)
1 (PCIe x1)
2 (PCI 32-bit)
--4
AIMB-566
1 (PCIe x4)
1 (PCI 32-bit)
--6
AIMB-564
1 (PCIe x16)
1 (PCIe x4)
2 (PCI 32-bit)
--
7
AIMB-562
1 (PCIe x1)
2 (PCI 32-bit)
--
2
Table B.3: PICMG 1.3 Backplane options/PICMG 1.3 底板选择 /PICMG 1.3
底板選擇
Model Name/
型号名称 /
型號名稱
Bus/总线/匯流排
PCI PCI/ISA ISA SATA
PCE-5B09-04A1E
1 (PCIe x16), Gen 3
3 (PCIe x4), Gen 3
4 (PCI 32-bit)
--
7
PCE-5B09-06A1E
1 (PCIe x16), Gen 3
1 (PCIe x4), Gen 3
6 (PCI 32-bit)
--
7
