Advantech SSPA/ SSPB User Manual

C-Band Hub-mount SSPA/ SSPB
An ISO 9001 : 2008 Company
Ref.: PB-AWMA-C-60-250-11025
www.advantechwireless.com
Specifications are subject to change without prior notice
SOUTH AMERICA
BRAZIL
Tel: +55 11 3054 5701
Fax: +55 11 5041 4026
info.brazil@advantechwireless.com
ARGENTINA
Tel: +54 11 4731 1034
Cel: +54 911 4492 5601
info.argentina@advantechwireless.com
EUROPE
UNITED KINGDOM
Tel: +44 1480 357 600
Fax: +44 1480 357 601
info.uk@advantechwireless.com
RUSSIA & CIS
Tel: +7 495 967 1859
Fax: +7 495 967 30 24
info.russia@advantechwireless.com
NORTH AMERICA
USA
Tel: + 1 703 788-6882
Fax: +1 703 788-6511
info.usa@advantechwireless.com
CANADA
Tel: +1 514 420-0045
Fax: +1 514 420-0073
info.canada@advantechwireless.com
Technical Specifications
60W
80W
100W
125W
150W
200W
250W
Electrical Characteristics
Availability in this series
CS, CR
√
√
√
√
√
√
√
CL,CP,CI,CX
√
√
√
√
√
Note 1
Note 1
Output power (P
SAT
)
+48 dBm
+49 dBm
+50 dBm
+51 dBm
+52 dBm
53 dBm
53 dBm
Output power (P1dB) min.
+47 dBm
+48 dBm
+49 dBm
+50 dBm
+51 dBm
52 dBm
53 dBm
Power gain @ maximum gain setting
56 dB min
60 dB min
65
65
Operating frequency range
See table A on front page
Max input power without damage
+10 dBm
Gain slope
0.6 dB max over 40 MHz
Gain flatness over 600 MHz
±1.0 dB max
Gain variation over temperature
±1.5 dB over full operating temperature range
Gain variation over 24 hours
±0.25 dB max at constant temperature & drive level
Gain adjustment range
20 dB min (0.1 dB resolution)
Input return loss
18 dB
Output return loss
19 dB
Noise power density
-70 dBm/Hz max in TX band
-150 dBm/Hz max in 3.4 –4.2 GHz RX band
Spurious at rated power
-65 dBc max
Harmonics at rated power
-60 dBc max
AM/PM conversion at rated power
2.5 /dB max (at P
1dB
),
1°/dB max. at 3 dB back-off
Third order IMD (2 tones 5 MHz apart)
-26 dBc max at 3 dB total back-off from rated P1dB
Group delay
Linear: 0.02 nsec/MHz max.
Parabolic: 0.003 nsec/MHz
2
max.
Ripple: 1.0 nsec p-p max.
Residual AM
(F* - frequency in kHz)
0-10 kHz -45 dBc
10 kHz - 500 kHz -20 (1.25+log F*) dBc
500 kHz - 1 MHz -80 dBc
Power Requirements
AC input voltage
110/220 VAC auto ranging (47-63 Hz)
Power consumption (nominal)
490W
550W
630W
710W
800W
950W
1100
Mechanical Characteristics
Dimensions (L x W x H)
18.50” x 9.80” x 9.21” (46.99 x 24.89 x 23.39 cm)
Weight (with mounting frame)
32 kg (70 lbs)
Interfaces:
RF input Type N (Female)
Output sample port Type N (Female)
AC Line MS3102R16-10P
Redundancy MS3112E14-12P
Discrete port MS3112E16-26P
RS-485 MS3112E10-6P
RF output CPR137 contact
(for CL series - CPR187)
Environmental Conditions
Temperature Operating
Storage
-30 C to +55 C Option 1: -40 C to +55 C; option 2: -50 C to +50 C
-55 C to +85 C
Humidity
100%, condensing (2” rain/hour)
Altitude
10,000’ AMSL, derated 2°C/1,000’ from AMSL
Note 1: Please refer AWMA-4000C
®
product datasheet

Advantech SSPA/ SSPB Specifications

Electrical Characteristics

output power (PSAT)	+48 dBm to +53 dBm
output power (P1dB) min.	+47 dBm to +53 dBm
power gain @ maximum gain setting	56 dB min to 65 dB min
max input power without damage	+10 dBm
gain slope	0.6 dB max over 40 MHz
gain flatness over 600 MHz	±1.0 dB max
gain variation over temperature	±1.5 dB over full operating temperature range
gain variation over 24 hours	±0.25 dB max at constant temperature & drive level
gain adjustment range	20 dB min (0.1 dB resolution)
input return loss	18 dB
output return loss	19 dB
noise power density	-70 dBm/Hz max in TX band
spurious at rated power	-65 dBc max
harmonics at rated power	-60 dBc max
AM/PM conversion at rated power	2.5 /dB max (at P1dB), 1°/dB max. at 3 dB back-off
third order IMD (2 tones 5 MHz apart)	-26 dBc max at 3 dB total back-off from rated P1dB
group delay Linear	0.02 nsec/MHz max.
residual AM 0-10 kHz	-45 dBc
residual AM 500 kHz - 1 MHz	-80 dBc

Power Requirements

AC input voltage	110/220 VAC auto ranging (47-63 Hz)
power consumption (nominal)	490W to 1100W

Mechanical Characteristics

dimensions (L x W x H)	18.50” x 9.80” x 9.21” (46.99 x 24.89 x 23.39 cm)
weight (with mounting frame)	32 kg (70 lbs)
interfaces	RF input Type N (Female), Redundancy MS3112E14-12P, RF output CPR137 contact

Environmental Conditions

temperature operating	-30 C to +55 C
temperature storage	-55 C to +85 C
humidity	100%, condensing (2” rain/hour)
altitude	10, 000’ AMSL, derated 2°C/1, 000’ from AMSL
