1.3 Package Contents
• One Wireless PCI Adapter
• Three External Antennas
• One CD-ROM (Drivers / Utility, User’s Manual)
If any of the above items is missing, contact your dealer immediately.
1.4 Before you start
You must have the requirements as follow,
• A computer with an available PCI slot
• At least a 300MHz processor and 32MB memory
• Windows 2000/XP/Vista support
• A CD-ROM drive
• Wireless PCI Adapter properly installed
1.5 Hardware Installation
STEP 1: Turn off your computer and remove its cover
STEP 2: Insert the PCI card to an available PCI slot firmly. Please refer to the illustration
below:
STEP 3:
Secure this card to the rear of the computer chassis and put back the cover.
STEP 4: Secure the antenna to antenna connector of the card. Please refer to the illustration
below:
To Next Page
