Fig. 15
Fig. 14
Fig. 16
Fig. 17
1 - Saw blade
2 - Combination square
3 - Turning table
1 - Dust-proof cover
View of blade not square with
turning table, adjustments are required.
1
2
3
1
2
1
Ø 254 mm
n
max.
7000
Ø 30 mm
48 HW 2.2 mm
Note: Before use, replace
blade bolt cover screw and
tighten securely to prevent
blade bolt cover movement
6
1
7
4
3
2
8
To tighten
To loosen
1
1 - Blade bolt cover screw
2 - Outer flange
3 - Blade bolt
4 - Saw blade
5 - Inner flange
6 - Blade bolt cover
7 - Lower blade guard
8 - Blade wrench
9 - Spindle lock button
