AEG Powertools PSD18B-254X - Page 9

9
9
Cross cut
1 - Work clamp
2 - Mitre detent release button
3 - Mitre lock knob
Fig. 21
Fig. 22
1 - LED button
Fig. 23
Fig. 24
1 - Push back
1
3
2
Shadow of
blade teeth
projected
onto workpiece
1 - Sliding lock knob
2 - Slide cut
3 - Pull lower guard lock lever
4 - Slide saw arm forward, pull lower guard lock out lever
to unlock lower guard, then push down.
4
3
2
1
1
1
