AEG 31050K - Page 2

MODEL
2
1 Radiant electric heating element Ø 145 mm 1200 W
2 Radiant electric heating element Ø 180 mm 1700 W
3 Halogen electric heating element Ø 145 mm 1200 W
4 Halogen electric heating element Ø 180 mm 1800 W
5 Signalling layout of heating elements position and residual heat indicator
6 Indicator that signals the connection of one or more heating elements
7 Residual heat indicator
8 Signalling layout of heating elements
9 Switch for plate n. 1 front
10 Switch for plate n. 2 front
12 Switch for plate n. 4 front
13 Switch for plate n. 1 bach
14 Switch for plate n. 2 bach
15 Switch for plate n. 3 bach
MODEL
MODEL
61040 K MODEL 31050 K MODEL
DESCRIPTION OF THE HOT PLATES
