Product disposal
Products marked with this symbol
must not be disposed of along with
household refuse but must be de-
livered to a waste collection centre
in accordance with current local
regulations.
Figures
Fig. 1. Installation of embedded sensor
Fig. 2. Installation of F 50-10 RH gutter sensor
and ATF 5 outdoor sensor
1 : Thermostat EM 50-1
2 : Gutter sensor F 50-10 RH
3 : Outdoor sensor ATF 5
Fig. 3. Ground application example
Fig. 4. Roof/gutter application example
Fig. 5. EF 50-25 H connection
Fig. 6. F 50-10 RH and ATF 5 connection
Fig. 7. Power supply and heating cable
connection
Fig. 8. EM 50-1 thermostat
EM 50-1
ATF 5
Abb. 4 / Fig. 4
EM 50-1
EF 50-25 H
Abb. 3 / Fig. 3
