21ENGLISH
Installation Procedure
Join Connector to the tap water line
Water Tube
Connector
Tap
7. Open the locking clips and grab
water coming from the refrigerator.
Remove plastic cap from water inlet
tting and discard cap. Replace the
connected tubes into the clips and
lock clips back in place to keep the
tubing in the right position.
Remove
the cap
from the
inlet tube
¼ inch
water
valve
plastic
tube
Plastic
cap
A
C
Connector to
connect the water
supply line to the
refrigerator tube
Adapter to connect
the water supply
8. After installation of refrigerator and
water line system, select “WATER”
on your control panel and press it for
1‐2 minutes to supply water into the
water tank and dispenser water.
To Next Page
