3.6 Reversing the freezer
compartment door
WARNING!
Before carrying out any
operations, remove the plug
from the power socket.
1. Close the freezer compartment door.
Unscrew the screw of the installation
button. Place the installation button
and the screw in a safe place.
2. Open a freezer compartment door
slightly. Pull down the freezer
compartment door and the cap from
the door upper bearing.
3. Remove the installation buckle and
install it on the opposite side.
4. Reverse the freezer compartment
door by 180 degrees. Install the cap
on the door upper bearing.
5. Fit the freezer compartment door and
close them.
6. Fix the installation button to the door
lower bearing. Press the installation
button until there is no gap between it
and cavity, then fix the screw.
7. Take out hole covers from a bag and
put them in the holes left after the
door hinge.
www.aeg.com10
