6
p. Remove the side clips holding the wheel well lining
as shown.
q. Remove the bottom clips holding the bottom plastic
tray.
r. Push back the fender liner as shown in the picture. s. Remove the plastic battery tray and remove the two
bolts as shown.
t. Locate and remove the two bolts on the side of the
vehicle’s frame.
u. Underneath the battery bracket, remove the 10mm
bolt that holds the air induction pipe to the battery
bracket.
