12. AUTOMATIC OPERATION
12.1. GENERAL DIAGRAM
Temperature
PASSWORD ENTRY
PASSWORD CONFIRMATION
Uo1 value displayed Uo2 value displayed
Uo1 value variation
Uo2 value variation
S2 temperature variation
ID1 status variation ID2 status variation ID3 status variation
N01 status variation N02 status variation HP hours variation
Heating element hours variation
Total hours variation
Heating element hours reset Total hours reset HP hours reset
H01 value displayed H22 value displayed
H01 value variation H22 value variation
AL1 value displayed AL6 value displayed
AL1 value variation
AL6 value variation
KEY
UP-DOWN buttons pressed instantly
Down button pressed for 3 sec.
SET button pressed and released instantly
the Set button can be pressed for 3 sec. to return to the start (S1 display)
