1. Specifications
• Memory: 3.9MB (more than 15 hour record with 0.1s sample rate)
• Sample time: 0.1 – 25.5s (user selectable in 0.1s steps)
• Dimensions: 20 x 33 x 6.5mm
Cable length approx. 10cm
• Weight: 8g with JR cable
• Power supply range: 4 – 12.6V
• Logging:
◦ altitude
◦ voltage
◦ temperature
◦ throttle
• Conforms to all existing competition rules (FAI F5J, ALES, etc.)
• Records multiple motor runs per flight
• OLED display (configurable screen)
• Telemetry support for Jeti Duplex EX® and Multiplex® M-Link
• Upgradeable firmware
• AerobTec Altis Flight manager software for Windows
2. Introduction
The AerobTec Altis v4 is a barometric altimeter designed especially to record the altitude of R/C aircraft
during flight with additional competition features. The unit has very small dimensions and a low weight.
The v4 senses barometric pressure variations caused by altitude changes of the aircraft. The altitude is
then calculated from pressure data and stored in the internal memory of the device.
The included system allows you to connect to a personal computer with a Windows (XP or higher)
operating system via USB. The supplied program will not only read the information from the device and
save it to the computer in various formats but it can also display the information in an advanced graph and
process the flight information in many other ways.
This altimeter has functions based on FAI F5J and Altitude limiting competitions (ALES) rules so it can be
used for these competitions.
The device and the software also provide some other complementary functions such as temperature,
throttle or voltage measurement and recording.
3. How it works
The Altis v4 uses a modern, fast, digital pressure sensor which allows it to sense very low pressure
AerobTec Altis v4 User Manual 3
