8
GENERAL INFORMATION
Introduction
This is the user manual for the 3020A, 3020C, 3021C, 3025, 3025C and 3026C Digital RF
Signal Generators, which are referred to generically in this document as ‘3020 Series’.
These Digital RF Signal Generators operate over the following frequency ranges:
3020A 250 MHz to 2.7 GHz
3020C 1 MHz to 3 GHz (usable to 100 kHz)
3021C 100 kHz to 3 GHz
3025 100 MHz to 6 GHz (usable to 76 MHz)
3025C 1 MHz to 6 GHz (usable to 100 kHz)
3026C 1 MHz to 6 GHz
and the following peak power level ranges:
30 MHz 85 MHz 3 GHz >3 GHz
3020A n/a n/a
120 dBm to +5 dBm
n/a
3020C
120 dBm to +6 dBm120 dBm to +6 dBm120 dBm to +6 dBm
n/a
3021C
121 dBm to +14 dBm121 dBm to +14 dBm121 dBm to +17 dBm
n/a
3025 n/a n/a
120 dBm to +5 dBm 120 dBm to +0 dBm
3025C
120 dBm to +6 dBm 120 dBm to +6 dBm 120 dBm to +6 dBm 120 dBm to +1 dBm
3026C
120 dBm to +14 dBm 120 dBm to +17 dBm 120 dBm to +17 dBm 120 dBm to +17 dBm
RF output can be continuous wave (CW) or modulated. Modulation can be internal analog
AM/FM, internal and external digital IQ, or external vector.
