Dropped Ceiling Track Mount
You can mount the AP550 in either a square or diagonal position on a standard 15/16"-wide track
(2.38 cm) in a dropped ceiling. A diagonal mount requires the diagonal mount bracket that ships
with the device. This section describes how to do both installations.
Square Dropped Ceiling Track Mount
Slip the mount tabs over the edges of the ceiling track as shown in the illustration, then rotate the
device slightly until the mount clips click into place over the track edges.
