Installation
09
3.4 Installation On-grid PV Inverter
Leave the enough space around inverter
, easy for accessing to the inverter
,
connection points and maintenance.
300mm
100mm
100mm
500mm
Step 1
242mm
36mm
36mm
Single-Phase(One MPPT T
racker):
Single-Phase(T
wo MPPT T
rackers):
328.5mm
26mm
26mm
35mm
10
12
