afx light BLADE5-FX User Manual

©Copyright LOTRONIC 2017 BLADE5-FX Page 10
11
Color 4
000- 255 see color table
12
Color 5
000- 255 see color table
13
Pan
000-255 Pan movement 0°~ 540°
14
Pan Fine
000-255 Pan Fine
15
Pan speed
000–255 Pan move from fast to slow
16
Pan rotate
000-005 Stop
006-126 Movement forward fast -> slow
127-128 Stop
129-249 Movement reverse Slow -> Fast
250-255 Stop
17
Tilt 1
000–255 Tilt1 movement 0°~ 360°
18
Tilt 1 Fine
000-255 Tilt 1 Fine
19
Tilt 1 speed
000–255 Tilt 1 move from fast to slow
20
Tilt 1 rotate 1
000-005 Stop
006-126 Movement forward fast -> slow
127-128 Stop
129-249 Movement reverse Slow -> Fast
250-255 Stop
21
Tilt 2
000–255 Tilt 2 movement 0°~ 360°
22
Tilt 2 Fine
000-255 Tilt 2 Fine
23
Tilt 2 speed
000–255 Tilt 2 move from fast to slow
24
Tilt 2 rotate
000-005 Stop
006-126 Movement forward fast -> slow
127-128 Stop
129-249 Movement reverse Slow -> Fast
250-255 Stop
25
Tilt 3
000–255 Tilt 3 movement 0°~ 360°
26
Tilt 3 Fine
000-255 Tilt 3 Fine
27
Tilt 3 speed
000–255 Tilt 3 move from fast to slow
28
Tilt 3 rotate
000-005 Stop
006-126 Movement forward fast -> slow
127-128 Stop
129-249 Movement reverse Slow -> Fast
250-255 Stop
29
Tile 4
000–255 Tilt 4 movement 0°~ 360°
30
Tilt 4 Fine
000-255 Tilt 4 Fine
31
Tilt 4 speed
000–255 Tilt 4 move from fast to slow
