24 Tilt 5 rotate
000-005 Stop
006-126 Movement forward fast -> slow
127-128 Stop
129-249 Movement reverse Slow -> Fast
250-255 Stop
30-Channel Mode
30CH MODE
Function
Value
1
Dimmer
000-255 0%~100%
2
Strobe
000-007 On
008-255 Strobe from slow to fast
3
Movement
000-007 No function
008-022 Movement 01
023-037 Movement 02
038-052 Movement 03
053-067 Movement 04
068-082 Movement 05
083-097 Movement 06
098-112 Movement07
113-127 Movement 08
128-142 Movement 09
143-157 Movement 10
158-172 Movement 11
173-187 Movement 12
188-202 Movement 13
203-217 Movement 14
218-232 Movement 15
233-247 Movement 16
248-255 Sound active
4
Movement Speed
000-255 Movement speed from slow to fast
5
Color Chase
000-015 No Function
015-255 Check the Color Chase Table
6
Chase Speed
000-255 Chase speed from slow to fast
7
Macro function
000-127
No function
128-250
Reset
251-255
No function
8
Color 1
000- 255 see color table
9
Color 2
000- 255 see color table
10
Color 3
000- 255 see color table
11
Color 4
000- 255 see color table
