AG 150 - Page 24

24
 
ITEM NO.
QUANTITY
PART NO.
DESCRIPTION
AG 150
1


MC6-1
Tapered bush
AG 150
2


MC7-1
Brace
AG 150
3


MC7-2
Head roller
AG
150
4 2 MC7-3 Idler roller
AG 150
5 1 MC7-4 Conveyor side front
AG 150
6 1 MC7-5 Conveyor side rear
AG 150
7 1 MC7-6 Conveyor belt
AG 150
8 2 MC6-2 Pulley
AG 150
9 2 MC6-3 Threaded tension bar
AG 150
10 1 MC6-4 Tension plate assembly
AG 150
11 2 MC6-5 V-belt (XPZ900 - STANDARD)
AG 150
12 1 MC6-6 Flange bearing (Conveyor)
AG 150
13 1 MC6-7 Flange bearing
AG 150
14 2 MC6-8 Hanger bearing
AG 150
15 2 MC6-9 M10 plain nut
AG 150
16 6 MC6-10 M20 plain nut
AG 150
17 3 MC6-11 M8 thin nyloc nut
AG
150
18 3 MC6-12 M10 plain washer
AG 150
19 3 MC6-13 M8 plain washer
AG 150
20 3 MC6-12 M10 plain washer
AG 150
21 16 MC6-12 M10 plain washer
AG 150
22 12 MC6-14 M10 *25 H.T Setscrew (8.8)
AG 150
23 2 MC6-15 M10*70 H.T Setscrew (8.8)
AG 150
24 3 MC6-16 M8 * 25 Cup Square Bolt
AG 150
25 4 MC6-17 M10 *25 Cup Square Bolt
AG 150
26 1 MC6-18 Hyd Motor DH 25 (Conveyor-Standard)
AG 150
27 1 MC6-19 Motor spacer
AG 150
28 4 MC6-20 3/8 - 16 unc *1 CSK Skt Screw
AG 150
29 2 MC7-7 Side skirt (large) metal clamp
AG 150
30 2 MC7-8 Side skirt (small) metal clamp
AG 150
31 12 MC6-21 M8 * 40 bolt
AG 150
32 12 MC6-13 M8 plain washer
AG 150
33 12 MC6-23 M8 Nyloc nut
AG 150
34 1 MC7-9 Auger
AG 150
35 1 MC7-10 V-belt guard
AG 150
36 2 MC6-24 M8 * 20 bolt
AG 150
37 3 MC6-13 M8 plain washer
AG 150
38 2 MC6-25 M8 spring washer
AG 150
39 4 MC6-26 M10 *35 bolt
AG 150
40 4 MC6-12 M10 plain washer
AG 150
41 10 MC6-27 M10 nyloc nut
AG 150
42 1 MC6-28 Flange bearing (Auger)
AG 150
43 1 MC7-11 Main bin
AG 150
44 1 MC7-12 Aperture plate
AG 150
45 4 MC6-29 M8 * 30 Cup Square Bolt
AG 150
46 8 MC6-22 M8 plain washer
AG 150
47 8 MC6-23 M8 nyloc nut
AG 150
48 4 MC6-14 M10 *25 H.T Setscrew (8.8)
AG 150
49 4 MC6-12 M10 Washer
AG 150
50 4 MC6-27 M10 nyloc nut
AG 150
51 1 MC6-36 Valve block
AG 150
52 4 MC6-31 M8 x 130 mm Cap Bolt
AG 150
53 4 MC6-22 M8 plain washer
AG 150
54 4 MC6-23 M8 Nyloc nut
AG 150
55 2 MC6-27 M10 nyloc nut
AG 150
56 2 MC6-12 M10 plain washer
AG 150
57 2 MC6-14 M10 *25 H.T Setscrew (8.8)
AG 150
58 2 MC7-12 Auger Motor cover seal
AG 150
59 1 MC7-13 Auger Motor cover
AG 150
60 2 MC6-32 M10 spring washer
AG 150
61 2 MC6-12 M10 plain washer
AG 150
62 2 MC6-14 M10 *25 H.T Setscrew (8.8)
AG 150
63 2 MC7-14 Adjustable plate
AG 150
64 1 MC6-33 Hydraulic motor Auger OMR390
AG 150
65 2 MC7-15 Rubber side skirt
AG 150
2 MC6-37 Middle range pulley ratio (140-80)
AG 150
2 MC6-38 Highest range pulley ration (140-60)

