This product is compatible with European standard mortise locks, and American standard deadbolt locks.
If Your Door Has an Interior Key
Ensure the key thickness is ≤ 5mm and the key handle length is ≤
39mm when inserted into the lock.
Confirm that you can still unlock the door from the outside with
the key when the interior key is inserted. If the existing lock
cylinder doesn't meet these requirements, it may cause serious
issues. Please replace it with a compatible one before installation.
You may choose to use the included EVA pad to enhance stability.
Adjust the thickness by stacking the EVA pads as needed.
If Your Door Has an Interior Knob
Remove the knob and keep the screws for later use. Select the appropriate adapter based
on the shape of the lock cylinder tailpiece.
If the knob cannot be removed from the existing lock cylinder, replace the lock cylinder before
installation.
Product Introduction
The U200 represents the next step in terms of both ease of use and functionality. Equipped with
Matter over Thread support, it ensures seamless interoperability across a broad range of smart home
ecosystems*. The U200 is designed to offer the convenience of keyless access to as many users as
possible without compromising on cutting-edge features. Unlike previous solutions, it operates the
existing lock cylinder and does not require drilling or modifying the door.
1. Euro Mortise Locks:
1) Supports Euro profile and select Scandi cylinders.
2) Ensure your cylinder includes an Emergency Function*.
2. US Deadbolt Locks:
1) Suitable for single-cylinder deadbolt locks.
2) Compatible with backsets of 2-3/8” (60 mm) and 2-3/4” (70 mm).
3. Additional Requirements:
1) Ensure you have a PH1 standard Phillips screwdriver available for installation.
2) For optimal installation results, we recommend following along with our installation video.
* To experience smart automations and other related functions, a 2-in-1 Matter Controllerand Thread Border Router
are required.
* Smart U200 Kit (Model: EL-D02D) Offline Version includes an NFC Card, AA Battery Adapter, and a Replaceable Panel
US Deadbolt Lock
Keypad
Use the two screws from Step 2 to attach the fixed plate to the door.
Use a tool to press down on the metal clip beneath the keypad, then push
upward to separate the keypad from the mounting plate.
Attach the keypad mounting plate to a suitable location on the outside of the door. It is recommended
that the distance between the keypad and the door lock does not exceed 2 meters
Insert AAA batteries into the keypad
If you want to remove the keypad:
Slide the keypad down to lock it in place, completing
the installation
Use a tool to press down on the metal clip beneath the keypad,
then push upward to separate the keypad from the mounting
plate. Insert AAA batteries into the keypad, then slide the
keypad down to lock it in place, completing the installation.
Lock Calibration
EU Profile Cylinder
Select Scandi Cylinder
US Deadbolt
5 adapters are included, with
four adapters having different
shapes on each end.
Screw Installation
Measure the thickness of the interior door lock cover and
the height of the lock cylinder protruding from the cover.
If the lock cylinder protrudes ≥ 3mm, you can secure the fixed plate using screws.
Use the provided hex key to tighten the three screws clockwise to secure the lock to the cylinder.
Over-tightening may affect the lock cylinder's performance, causing issues with locking and unlocking.
3M Adhesive Installation
If the lock cylinder protrudes ≤ 3mm, you can use the 3M adhesive method to secure the
fixed plate, or replace the lock cylinder before installation.
Clean the area around the fixed plate and cylinder to remove dust. Peel off the yellow backing of the
3M adhesive and apply it to the fixed plate. Then peel off the red backing and attach it to the lock
cylinder. Press and hold the fixed plate for 60 seconds to enhance adhesive stability.
To remove the fixed plate, use a hairdryer to heat the adhesive, making it easier to detach.
Installing the Key or Adapter
If your knob tailpiece is cylindrical, use the original knob screws to secure the adapter.
Note: Aer removing the fixed plate, pre-tighten the screws by turning them 10 times clockwise to speed up the
installation process.
What’s in the Box
Aqara Rechargeable BatteryKeypad
Backplate Accessory
(for Scandi or US locks)
Hexagon Screwdriver
Cylinder Adaptor Kit × 5 Eva Foam × 3
AAA Battery × 4
3M Sticker Power Bank Pouch × 1
USB-A to USB-C CableLock
Screw Kit
Phillips Head Machine Screw PM3 × 14mm
Countersunk Self-Tapping Screw M3 × 25mm
User Manual
Knob
Reset Button
Set Button
Magic Pair QR Code
Matter QR Code
Battery Compartment
Indicator Light
Indicator Light
NFC Sensing Area
Lock / Return Button
Confirm Button
Fingerprint Area
Reset Button
Set Button
Lock / Return Button
Confirm Button
* Check this website for compatibility issues: https://www.aqara.com/en/u200-installation-methods
* An Emergency Function enables the cylinder to be unlocked from the outside using a key, even if another key is
already inserted on the inside.
Aqara Home
Installation Video
≤39mm
≤5mm
？？
180°
or
1－20mm
1
2
≤2m
Battery Indicator
Red
Green
Low battery or charging
Battery fully charged
Indicator Light
EU Mortise Lock
Note: Adapters are consumable parts and may
need replacement aer about 2 years. You can
purchase new adapters or download 3D files
from the Aqara website to print your own.
Aqara cannot guarantee the strength and
durability of self-printed adapters.
Note: Adapters are consumable parts and
may need replacement aer about 2
years. You can purchase new adapters or
download 3D files from the Aqara website
to print your own.
Aqara cannot guarantee the strength and
durability of self-printed adapters.
Open the battery cover and secure the lock to the fixed plate with screws. Rotate the knob to ensure
smooth locking and unlocking. Adjust the screw tightness if necessary to avoid operational issues.
Insert the batteries, cover the battery plate, and complete the lock installation. Next, proceedwith the
keypad installation.
Before installation, it is recommended
to use tape to secure the outdoor part
of the door lock.
Remove the indoor knob and keep the
two mounting screws in a safe place,
as we will need to use these screws
again shortly.
Remove the fixed plate accessory, rotate it 180 degrees, and reinstall it. Depending on the distance
between the screw holes, you might need to use a different accessory.
Note: Aer installation, ensure that the tailpiece of the lock cylinder does not rub against the fixed plate and should
protrude 1-20mm from the fixed plate.
Note: If the tailpiece is longer than 20mm, you may consider trimming it.
Install the appropriate adapter
Install the battery and cover it with the battery cover.
Open the battery cover of the door lock and use screws to attach the door lock to the fixed plate. Then,
turn the knob to check if the door lock can be smoothly locked and unlocked.
Note: If the screws are tightened too much, it may cause difficulty in locking and unlocking.
Please adjust the screw tightness accordingly.
Connecting to Aqara Home
Local Settings
Adding Users on the Door Lock
Quiet Lock and Unlock Mode
Auto-Lock
Door Lock
Download the Aqara Home app from the Apple App Store, Google Play, Xiaomi GetApps, Huawei App
Gallery, or by scanning the provided QR code. Power on the device, bring your phone near it, open the
app, tap the "+" icon, select "Smart Lock U200," and follow the instructions.
Aer setting up the Aqara Smart Door Lock U200 in the Apple Home app, add a home key in the Wallet
app to easily and securely access your home with your iPhone:
Local Settings through the Keypad contains:
1) Add user: Add users and register fingerprints and passwords.
2) Remove users: Remove users and their credentials.
3) Volume & Language: Customize volume and language settings.
4) Matter reset: Reset the Matter ecosystem already bound.
5) Door lock calibration: Calibrate the door lock.
Aer installation, users can calibrate the door lock using the Aqara Home app or directly on the lock.
Here's how to calibrate on the lock:
Note:
Two beeps during calibration indicate failure. The lock won't function properly if calibration is incomplete.
If calibration fails or is inaccurate, check if the mounting screws are too loose or tight and adjust them before
retrying.
If calibration issues persist, use the manual calibration feature in the Aqara Home app
1. Close the door and unlock it from the inside. Press and hold the Set button on the lock for 3
seconds to start calibration.
2. The lock will beep twice, then rotate to the unlock and lock positions. It will play a tune when
calibration is complete.
1. To control this Matter-certified accessory, use the latest iOS or iPadOS. You'll need an Apple home
hub, such as HomePod mini, HomePod (2nd gen), or Apple TV 4K (3rd gen, Wi-Fi + Ethernet). Other
HomePod or Apple TV models require a compatible Thread border router. For the home key feature,
you need an iPhone XS or newer with iOS 17.1 or higher, and an Apple Watch Series 4 or newer with
watchOS 10.1 or higher.
2. Aer connecting to Apple Home, the "Wallet" app will automatically generate the Apple home keys.
3. Apple, Apple Watch, HomePod, HomePod mini, and iPhone are trademarks of Apple Inc., registered
in the U.S. and other countries. The "Works with Apple Home" badge is a trademark of Apple Inc.
4. Using the "Works with Apple" badge means the accessory is designed and certified to meet Apple's
performance standards. Apple is not responsible for the device's operation or compliance with
safety and regulatory standards. or Apple Watch.
1. If you are an Aqara Home user and have set up an admin user, press and hold the confirm button on
the keypad for 3 seconds, then verify the admin credentials to access the local settings.
2. If you are using another Matter ecosystem and have set up the first user, press and hold the confirm
button on the keypad for 3 seconds, then press the setup button on the indoor lock to access the
local settings.
3. On the local settings, follow the voice prompts and press the number key (1) on the keypad to add a
new user. Set a password and fingerprint for the new user. Press the Lock button (Return button) to
exit the settings page aer completing the process.
4. If the lock is bound to both Aqara and another Matter ecosystem, you must verify the Aqara admin
credentials on the keypad to access the local settings.
The U200 features Quiet unlock and lock functions locally:
1. Outdoor Quiet Unlock: Press the confirm button on the keypad, then complete the unlock
verification. If successful, the lock will unlock Quietly.
2. Outdoor Quiet Lock: Press the confirm button on the keypad, then press the lock button. The lock
will lock Quietly.
1. Indoor Quiet Unlock: Slowly turn the door lock knob in the unlock direction for a Quiet unlock.
2. Indoor Quiet Lock: Slowly turn the door lock knob in the lock direction for a Quiet lock.
1. You may need to calibrate the lock's open and close angles using the Aqara Home app before
enabling this feature.
2. Aer closing the door, the lock will attempt to lock automatically. Ensure the lock is secure before
leaving.
3. Aer extended use, you may need to recalibrate the lock's open and close angles.
Connecting to other Matter Ecosystems
Adding Apple Home Key (for iOS Users)
1. Ensure you have a 2-in-1 Matter Controller and Thread Border Router for third-party ecosystems for
the binding. Power on the door lock, press the Set button to enter pairing mode, then use the
third-party app to scan the Matter QR code or enter the setup code from the Lock or user manual.
2. To add the device to another ecosystem aer binding it to Matter, use the Matter app to share the
device with other platforms.
3. If you want to bind the device to another ecosystem and remove the current one, first remove the
device from the app, then reset the door lock or go to the local settings page to reset the Matter
ecosystem. The door lock will revert to its initial pairing mode. Refer to the Local Settings section of
the manual for reset instructions.
1. This product supports Aqara Magic Pair technology. Aer powering on the device, press the setup
button to enter pairing mode. The Aqara Home app will automatically detect the device. Select it
and follow the app instructions to complete setup.
2. Keep your phone close to the device during pairing. Ensure your phone is connected to the internet
and Bluetooth is enabled.
3. Follow the app instructions to scan the QR code on the product or enter the 8-digit pairing code to
confirm the addition of the device.
You can scan the following code for download Aqara Home app or check the Installation Video directly.
Note: Enjoy more exclusive features with the Aqara Home app without needing a hub, within Bluetooth range.
Note: In the early stages of the Matter ecosystem, different platforms support varying features. For example, some
platforms do not support adding door lock passwords. For a better user experience, we recommend adding the
device in the Aqara Home app.
Buttons Features
Operations
Set Button
Reset Button
Enter Paring Mode
Door Lock Calibration
Door Lock Reset
Single press the Set Button
Long press (3s) the Set Button
1) Ensure your lock is only bound to one Matter ecosystem.
2) Initiate Reset Mode on the keypad by pressing the Lock
and Confirm buttons for 5s simultaneously.
3) Press and hold the Reset button on the lock for 3s.
Keypad
Buttons Features Operations
Lock
Button
Confirm
Button
Lock
Quiet Lock Mode
Verify Password
Quiet Unlock
Quiet Lock Mode
Local Settings
Single press the Lock Button
Long press (3s) Lock Button
Single press the Confirm Button aer entering the password
Single press the Confirm Button followed by password or
fingerprint unlocking
Single press the Confirm Button followed by single press Lock Button
Aqara Home Users: Long press (3s) Confirm Button until you hear
the voice prompt
Matter Users: Long press (3s) the Confirm Button and press the
Set Button on the Lock
Note: Customize Quiet functions using the Aqara Home app.
Note: Features like Away Mode, Night Latch Mode, Auto Unlock Mode, and others will be gradually rolled out via
OTA updates around the end of H2 2024 through Aqara Home app.
To use the auto lock function, add the lock in the Aqara Home app and enable the auto lock feature in
the settings. Please note:
Resetting the Lock and Keypad
1. If bound to Aqara Home: Press and hold the lock button and confirm button on the keypad for 5
seconds to enter reset mode. Verify the admin password or fingerprint on the keypad. If correct, the
lock will reset to factory settings and erase all data.
2. If bound only to Matter ecosystem: Press and hold the lock button and confirm button on the
keypad for 5 seconds to enter reset mode. Then press and hold the reset button on the lock for 3
seconds. The lock will reset to factory settings and erase all user data.
You can reset the lock using either of these methods:
Exclusive Features
We recommend using the Aqara Home app to access exclusive features and detailed settings such as
Manual Calibration, Auto Lock, Auto-Turn Lock/Turn to Lock, Pull Spring Feature, and more.
Reset Smart Lock U200
Power Setup
1. Aqara Home Users
2. Other Matter Ecosystem Users
1. Door Lock
The Smart Lock U200 supports charging while in use. Place the charger in the supplied pouch and
hang it on the door handle to charge the lock.
2. Keypad
You can use LR3 AAA batteries or have a professional electrician connect a 12V-24V 0.5A AC/DC power
supply to your keypad.
FAQ
If you have any other questions about this product, you can find more product information on the
following website: https://www.aqara.com/en/u200-installation-methods
Online Customer Service: www.aqara.com/en/support.html
Manufacturer: Lumi United Technology Co., Ltd.
Address: Room 801-804, Building 1, Chongwen Park, Nanshan iPark, No. 3370,
Liuxian Avenue, Fuguang Community, Taoyuan Residential District, Nanshan District,
Shenzhen, China
Email: support@aqara.com
Note: If you have already bound the door lock to the Aqara Home app
or a third-party Matter ecosystem, you will need to verify the Aqara
administrator password or fingerprint, or press the reset button on
the door lock to disable the alarm. Otherwise, the keypad will
continue to emit an alarm sound.
or
1 2 3
≤3mm
≥3mm
21
Installation Methods
Installation Requirements
To use the following features, add the lock in the Aqara Home app and enable the auxiliary rotation
feature in the settings:
1) Press and hold the Lock and Confirm buttons on the keypad simultaneously for 3 seconds to enter
Reset Mode.
2) Aer the prompt, press and hold the Reset button on the lock for 3 seconds. The lock will clear all
user data and restore factory settings.
1) Press and hold the Lock and Confirm buttons on the keypad simultaneously for 3 seconds to enter
Reset Mode.
2) Aer the prompt, verify with the admin password or fingerprint. If correct, the lock will clear all user
data and restore factory settings.
