32
Working radius 3 ft. -1000 ft. (1 m - 300 m),
laser dependent
Detection accuracy ±3/32” (±2.5 mm)
Range of reading Elevations from 3.2‘ (.99m)
to 13.2‘ (4.02 m)
Choice of units • Metric
• Feet/10ths/100ths
• Feet/inches/16ths
Beam capture angle 120° minimum
Beam capture height 6.5" (165 mm), dependent on
laser and distance
Detectable laser beam Visible and infrared
(610nm to 780 nm)
Power supply/battery life Control panel:
(3) AA batteries for min. 60 hrs.
Laser receiver: (3) AA batteries
for min. 3000 measurements
Standby of capture mode After 30 seconds (no use)
Automatic shut-off After 5 minutes (no use)
Operating temperature 14°F to 122°F (-10°C to +50°C)
Storage temperature -40°F to 158°F (-40°C to +70°C)
Environmental IP54 for water and dust resistance
Weight 8 lbs. (3.6 kg)
Dimensions Total extended height:
13.4 ft (4,07 m);
closes to 3.8 ft. (1,15m)
Specifications subject to change without notice.
Specifications
1. General information and start-up 2
Specifications
Overview with battery installation
2. Operation 6
Elevation reading
Cut and fill mode
Tape measure mode
3. Troubleshooting 9
4. Care and handling, technical tips 10
5. Safety and warranty 10
Although the SmartRod is easy to use, we recommend that you
read this manual before use, as it functions differently than a
standard laser receiver.
The SmartRod is a laser receiver built into a telescoping rod, with
unique features that eliminate the usual calculations required when
using a receiver on a grade rod. It provides a digital readout in
three modes: basic elevation readings, cut-and-fill calculations, and
height and width measurements (tape measuring mode, not
requiring a laser). It can receive reference elevation information
from all rotating lasers.
The SmartRod has these advanced features:
• LCD showing elevation, measurements, settings, and status
of functions
• Cut-and-fill mode that indicates how far a measurement is from a
previous reference reading
• Choice of units: metric; ft/10ths/100ths; and ft/inches/16ths
• Uses linear receiving technology and has a wide 6.5”(165mm)
reception range for capturing the beam quickly.
Table of contents
1. General Description
