4.13 Replace the Film Knives
Before starting the procedure
When the knives do not cut the film correctly, you must replace the knives.
CAUTION: Risk of injury.
Put on protective gloves when the knives are changed.
Procedure
1. Make sure that the machine is "OFF". Refer
to the shutdown procedure for maintenance.
2. Loosen the eight bolts (1).
3. Carefully remove the used knife (2) and
install a new knife.
4. Tighten the eight bolts.
5. Do steps 2-4 to replace the other knife.
GUID-3A9E38DB-0B32-40CF-9285-24B119150F5C-high.jpg [High]
Fig. 21
(1)
Bolts.
(2) Knife.
GUID-EA715CD9-20CC-4839-869C-5331D736A2DD [V1]
4. Maintenance and Lubrication
134 Baler Wrapper Combination
4900.LE.EN01
