4.18 Adjust the Tension of the Film Stretching Unit
Before starting the procedure
Yearly and when necessary check and adjust the film stretching unit tension.
Procedure
1. Make sure that the machine is "OFF". Refer to the shutdown procedure for maintenance.
2. Adjust the nut (1) on the eyebolt until the
spring (2) extends to 95 mm.
GUID-D6648C64-BD68-4FDB-8595-B90EA8D7BC04-high.jpg [High]
Fig. 27
(A) 95mm.
GUID-843B55C1-8D79-4DC1-9D0D-604BD39D1C67-high.jpg [High]
Fig. 28
(1)
Nut.
(2) Spring.
GUID-27AFE6DD-A418-4E75-A3DC-13C9A48C3324 [V1]
4. Maintenance and Lubrication
Baler Wrapper Combination 139
4900.LE.EN01
