6.1 Technical Specifications
Item RPC 130 F RPC 160 V
Bale chamber 18 Ribbed Rollers 4 endless belts
Bale chamber diameter 1.30 m (4.3 ft) 0.90 - 1.60 m (3.3 - 5.2 ft)
Bale chamber width 1.23 m (4.0 ft)
Pick-up working width 2.00 / 2.25 / 2.40 m (6.6 / 7.4 / 7.9 ft)
Power Take-O (PTO) speed 540 rpm / 1000 rpm
Cutting device 13 / 17 / 25 knives
Hydroflex Standard
Varionet net wrap Standard
Wrapping film pre-stretch rate 55/ 70/ 90 %
Wrapping film roll size 50 - 75 cm (20 - 29.5 in)
Bale tipper Optional
Bale Mat Optional
Maximum weight on the axle 5300 kg (11684 lb)
Maximum weight on the draw bar
coupling
1000 kg (2205 lb)
Maximum speed 40 km/h (25mph)
Brake system Pneumatic / Hydraulic
Noise level in the tractor with the
cabin closed
< 70 dB (A)
Dimensions of the license plate
position
255 × 165 mm (10 × 6.5 in)
Tyre size Maximum speed Tyre pressure
620/55-R26.5 25 km/h (15 mph) 1.8 - 3.6 bar (26 - 52 psi)
620/55-R26.5 40 km/h (25 mph) 1.8 - 3.6 bar (26 - 52 psi)
Only use tyres that have been approved for the maximum axle load of the machine (see value A1 on the
VIN-plate) at a speed of 40 km/h
Guide wheels (not allowed on public roads)
170/60-8 2.0 bar (29 psi)
Tyres
Tightening torque for the wheel nuts
Only for wheel nuts 550 Nm (405 lbft)
Wheel nut tightening torque
GUID-50F5DC2E-0034-4A50-A888-205F9214244C [V1]
6. Specifications
Baler Wrapper Combination 159
4900.LE.EN01
