• Monitor the rear of the machine to prevent accidents.
The cameras are on the left and the right side of the machine, the work lamps give the cameras sucient
light for a good view. The work lamps have a power switch.
2.3.21 Bale Tipper (optional)
The bale tipper is a metal frame towed behind the wrapper.
The tipper frame turns the bale 90° before it releases the bale to the ground.
The bale stays on its end to prevent movement of the bale.
The bale tipper's guide wheel is adjustable in three positions.
2.3.22 Bale Mat (optional)
The bale mat is installed on the wrapping table.
When the bale is released from the wrapping table, it falls first on to the mat and then on to the ground.
This helps prevent damage to the wrapping film from sharp stubble.
GUID-445845B8-D1CB-4A0C-B424-4685060113FA [V1]
GUID-B2110A20-7381-4848-865F-CEA11532CE11 [V1]
2. Introduction
Baler Wrapper Combination 45
4900.LE.EN01
