3. Push to go to the page “Field statistics”.
4. Make the selection of the field (or customer) for more data.
5. If available and if necessary, make the selection of knife bank, push
to go to the page “Tasks”.
6. Make the selections.
7. Push to go to the Home page.
3.4.14 Open or Close the Side Covers
When the side covers on the left and right side are open some parts are easier to get to.
Procedure
1. Open the cover.
a) Use a 13 mm (0.5 in) wrench to turn the
lock (1)
b) Use the lever (2) to open the cover. The
cover will turn up.
2. Close the cover.
a) Push the cover down until first the lever
and then the lock engage. Make sure that
the lock fully engages.
GUID-D15212CB-75B9-43D1-B0FE-179D15B54B07-high.jpg [High]
Fig. 45
GUID-AC7FFF02-A257-4FBB-A811-B2F9E77BC587 [V1]
3. Operation
Baler Wrapper Combination 97
4900.LE.EN01
