1100 Series Nano Pump Service Manual 165
Parts and Materials 4
Electro Magnetic Proportional Valve (EMPV)
Table 19 EMPV Assembly
Item Description Part Number
1 EMPV — complete assembly G1361-60000
2 Filter to EMPV capillary G1375-87400
3 EMPV to flow sensor capillary (nanoflow sensor) G1375-87321
4 Screw 0515-0850
Figure 29 EMPV Assembly
1
2
3
4
