74 1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual
4
Preparing the Fraction Collector
Setting up the Fraction Collector with the Instrument Control Interface
Instrument Configuration
Use the Instrument Configuration dialog box to examine and, if necessary, modify
your instrument configuration. The Configurable Modules panel contains a list
of all modules available for configuration. The Selected Modules panel contains
the list of configured modules.
Auto Configuration: Under Communication settings, select either the Host Name
option or the IP address option and enter the appropriate value for the host
computer to enable automatic detection of the hardware configuration. The
system configures the instrument automatically with no further manual
configuration necessary.
The Fraction Collector configuration parameters are in four sections:
• Communication
• Module List
•Peak Detectors
• Linked Pump
Table 9 Instrument configuration parameters
Parameter Description
Communication: The parameters in this dialog
box are detected automatically during
autoconfiguration.
• Device name,
•Type ID,
• Button: Connection settings
Module List:
• Module identifier (Type ID: Serial number),
• Device name,
• Button: Configure (Device name, Serial
number, Firmware revision)
To Next Page
