Agilent Technologies 33120A Service Guide

Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
R629 0699-2712 RESISTOR 255 +-1% .125 W TKF TC=0+-100 28480 0699-2712
R630 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-10 28480 0699-1415
R631 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R632-R633 0699-1384 RESISTOR 4.64K +-1% .125 W TKF TC=0+-100 28480 0699-1384
R634 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-10 28480 0699-1415
R635 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R636-R637 0699-1384 RESISTOR 4.64K +-1% .125 W TKF TC=0+-100 28480 0699-1384
R638-R639 0699-1344 RESISTOR 10 +-1% .125 W TKF TC=0+-100 28480 0699-1344
R640 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R641 0699-2631 4 RESISTOR 2K +-1% .125 W TKF TC=0+-100 28480 0699-2631
R642 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R643 0699-2196 1 RESISTOR 78.7 1% 1206 .125 W 200 V TC=100 28480 0699-2196
R644 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-100 28480 0699-1415
R645 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R646 0699-1352 1 RESISTOR 21.5 +-1% .125 W TKF TC=0+-100 28480 0699-1352
R647-R648 0699-1332 2 RESISTOR 196K +-1% .125 W TKF TC=0+-100 28480 0699-1332
R649 0699-1392 2 RESISTOR 11K +-1% .125W TKF TC=0+-100 28480 0699-1392
R650 0699-1330 3 RESISTOR 100K +-1% .125 W TKF TC=0+-100 28480 0699-1330
R651 0699-1392 RESISTOR 11K +-1% .125 W TKF TC=0+-100 28480 0699-1392
R652 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R653 0699-2103 RESISTOR 49.9 +-1% .125 W TKF TC=0+-100 28480 0699-2103
R654 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R655 0699-2631 RESISTOR 2K +-1% .125 W TKF TC=0+-100 28480 0699-2631
R656 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-100 28480 0699-1415
R657 0699-1366 3 RESISTOR 82.5 +-1% .125 W TKF TC=0+-100 28480 0699-1366
R658 0699-1360 1 RESISTOR 46.4 +-1% .125 W TKF TC=0+-100 28480 0699-1360
R659 0699-1432 RESISTOR 511 +-1% .125 W TKF TC=0+-100 28480 0699-1432
R660 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R661 0699-1398 2 RESISTOR 21.5K +-1% .125 W TKF TC=0+-100 28480 0699-1398
R662 0699-1330 RESISTOR 100K +-1% .125 W TKF TC=0+-100 28480 0699-1330
R663 0699-1421 2 RESISTOR 178 +-1% .125 W TKF TC=0+-100 28480 0699-1421
R664 0699-2883 3 RESISTOR 1.4K 1% 1206 .125 W 200V TC=100 28480 0699-2883
R701-R702 0699-2843 2 RESISTOR 100K +-0.1% .125 W TF TC=0+-25 11502 W1206R031003BT
R703-R704 0699-2489 RESISTOR 10K +-0.1% .125 W TF TC=0+-25 11502 W1206R031002BT
R705-R706 0699-2631 RESISTOR 2K +-1% .125 W TKF TC=0+-100 28480 0699-2631
R707-R708 0699-1422 2 RESISTOR 196 +-1% .125 W TKF TC=0+-100 28480 0699-1422
R710 2100-4199 1 RESISTOR-TRMR 100 20% TKF TOP-ADJ 1-TRN 32997 3314G-1-101E
R711 0699-2883 RESISTOR 1.4K 1% 1206 .125 W 200V TC=100 28480 0699-2883
R712 0699-1394 1 RESISTOR 14.7K +-1% .125 W TKF TC=0+-100 28480 0699-1394
R713 0699-1366 RESISTOR 82.5 +-1% .125 W TKF TC=0+-100 28480 0699-1366
R715-R716 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-100 28480 0699-1415
R717 0699-2883 RESISTOR 1.4K 1% 1206 .125 W 200V TC=100 28480 0699-2883
R718 0699-1351 2 RESISTOR 19.6 +-1% .125 W TKF TC=0+-100 28480 0699-1351
R719-R720 0699-1415 RESISTOR 100 +-1% .125 W TKF TC=0+-100 28480 0699-1415
R722 0699-1366 RESISTOR 82.5 +-1% .125 W TKF TC=0+-100 28480 0699-1366
R723 0699-1351 RESISTOR 19.6 +-1% .125 W TKF TC=0+-100 28480 0699-1351
Chapter 7 Replaceable Parts
33120-66521 – Main PC Assembly
120
