98 Replaceable Parts
Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA
Reference
Desig.
Applicable Models Agilent Part No. Description
C202-C204 0160-4801 Capacitor l00PF 5%
C205 0160-4835 Capacitor .lUF 10% 50V
C206 65/6641A 0160-4835 Capacitor .lUF 10% 50V
C207 65/6641A 0160-4801 Capacitor l00PF 5%
C208, C209 65/6641A 0160-6806 Capacitor .lUF 400V
C211 65/6641A 0160-4812 Capacitor 220PF 5%
C301-C304 65/6641A 0160-480l Capacitor l00PF 5%
C305, C36 65/6641A 0160-4835 Capacitor .lUF 10% 50V
C307 65/6641A 0160-4801 Capacitor l00PF 5%
C309 65/6641A 0160-6806 Capacitor .lUF 400V
C405 65/6641A 0180-4461 Capacitor 27000UF 35V
65/6642A 0180-4462 Capacitor 12000UF 63V
65/6643A, 0180-4465 Capacitor 4700UF l00V
65/6644A 0180-4463 Capacitor 2700UF 150V
65/6645A 0180-4464 Capacitor 1200UF 250V
C406 65/6641A 0180-4461 Capacitor 27000UF 35V
65/6642A 0180-4462 Capacitor 12000UF 63V
65/6643A 0180-4465 Capacitor 4700UF l00V
C407 65/6641A 0180-4461 Capacitor 27000UF 35V
C408 65/6641A 0180-4461 Capacitor 27000UF 35V
C413 0160-5469 Capacitor lUF 10% 50V
C414, C415 0160-5422 Capacitor .047UF 20%
C416 0180-3963 Capacitor 17000UF 16V
C418 65/6641A, 65/6642A 0160-5422 Capacitor .047UF 20%
65/6643A, 65/6644A 0160-0168 Capacitor .lUF 10%
65/6645A 0160-6806 Capacitor .lUF 10%
C450 0160-4183 Capacitor l000PF 20%
C451 65/6641A 0160-4183 Capacitor l000PF 20%
C452 0160-4413 Capacitor .6UF 10%
C501 0160-5422 Capacitor .047UF 20%
C502 0160-4805 Capacitor 47PF 5% l00V
C503 0160-4805 Capacitor 47PF 5% l00V
C504 0160-5422 Capacitor .047UF 20%
C505 0180-4129 Capacitor lUF 35V
C506 0160-4801 Capacitor l00PF 5%
C507 0160-5422 Capacitor .047UF 20%
C509 0160-5422 Capacitor .047UF 20%
C510 0160-4801 Capacitor l00PF 5%
C512 0160-5422 Capacitor .047UF 20%
C513 0160-4801 Capacitor l00PF 5%
C515 0160-5422 Capacitor .047UF 20%
C516 0160-4801 Capacitor l00PF 5%
C517 0160-5422 Capacitor .047UF 20%
C518 0160-5422 Capacitor .047UF 20%
C519 0180-4129 Capacitor lUF 35V
C520 0160-5098 Capacitor.22UF 10%
C521 0160-5098 Capacitor.22UF 10%
C522 0160-5098 Capacitor.22UF 10%
