Chapter 4 265
Key Function Descriptions
Key Descriptions
FREQUENCY COUNTER OFF
FREQUENCY COUNTER
RESOLUTION
10 kHz
FREQUENCY DISPLAY ON
FREQUENCY MODE CENTER FREQUENCY, SPAN
FREQUENCY OFFSET 0 Hz
GATE OFF
GATE CONTROL EDGE
GATE DELAY 3µs
GATE LENGTH 1µs
GATE POLARITY POSITIVE
GRATICULE ON
INPUT ATTENUATION 10 dB, AUTO
MARKER MODE OFF
MAX MIXER LEVEL −10 dBm
MIXER INT
MIXER CONV LOSS 30.0 dB, OFF
NOISE MARKER OFF
PEAK EXCURSION 6 dB
PEAK THRESHOLD −130 dBm
PRESELECTOR PEAK
TABLE
factory data (for Agilent 8561E/EC,
Agilent 8562E/EC, Agilent 8563E/EC,
Agilent 8564E/EC, Agilent 8565E/EC)
RBW/SPAN RATIO 0.011
REFERENCE LEVEL 0 dBm
REFERENCE LEVEL
OFFSET
0 dB, OFF
RESOLUTION BW 1 MHz, AUTO
SIGNAL IDENTIFICATION OFF
SIGNAL TRACK OFF
Table 4-7 Instrument State after PRESET Is Executed
Function State
