116 Chapter2
Making Adjustments
16. Frequency Response of the 8592L/94L, 8593E/94E/95E/96E, and 8594Q
Frequency Response Errors Band 0
1.596 _____________________ 2.0
1.668 _____________________ 2.0
1.740 _____________________ 2.0
1.812 _____________________ 2.0
1.884 _____________________ 2.0
1.956 _____________________ 2.0
2.028 _____________________ 2.0
2.100 _____________________ 2.0
2.172 _____________________ 2.0
2.244 _____________________ 2.0
2.316 _____________________ 2.0
2.388 _____________________ 2.0
2.460 _____________________ 2.0
2.532 _____________________ 3.0
2.604 _____________________ 3.0
2.676 _____________________ 3.0
2.748 _____________________ 3.0
2.820 _____________________ 3.0
2.892 _____________________ 3.0
Frequency Response Errors Band 1
6.100 _____________________ 6.0
6.284 _____________________ 6.0
6.468 _____________________ 6.0
6.652 _____________________ 7.0
6.836 _____________________ 7.0
7.020 _____________________ 7.0
7.204 _____________________ 7.0
Table 2-8 Frequency Response Errors
Column 1 Frequency
(GHz)
Column 2
Measuring Receiver
Reading (dB)
Column 3
CAL FACTOR
Frequency (GHz)
To Next Page
