Appendix B Verification and Calibration
146 Series N6700 User’s Guide
Test Record Form – Agilent N6732B and N6742B
Agilent N6732B and N6742B Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
− 4 mV
Vout − 20 mV
7.973 V
Vout − 28 mV
__________
__________
__________
__________
+ 34 mV
Vout + 20 mV
8.027 V
Vout + 28 mV
CV Load Effect
Both
− 6 mV
__________ + 6 mV
CV Source Effect
Both
− 2 mV
__________ + 2 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
+ 12 mV
+ 2 mV
Transient Response
Voltage at 200 µs N6732B
N6742B
− 80 mV
− 100 mV
__________
__________
+ 80 mV
+ 100 mV
Constant Current Tests
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
Both
Both
N6732B
N6742B
N6732B
N6742B
− 20 mA
Iout − 10 mA
6.2206 A
12.46 A
Iout − 19.37 mA
Iout − 29 mA
__________
__________
__________
__________
__________
__________
+ 60 mA
Iout + 10 mA
6.2794 A
12.54 A
Iout + 19.37 mA
Iout + 29 mA
CC Load Effect
Both
− 2 mA
__________ + 2 mA
CC Source Effect
Both
− 1 mA
__________ + 1 mA
Instrument Settings
Test Description N6732B N6742B
Voltage Programming & Readback, Zero Voltage 15 mV, 6.25 A 15 mV, 12.5 A
Voltage Programming & Readback, High Voltage 8 V, 6.25 A 8 V, 12.5 A
CV Load Effect, Source Effect, Ripple and Noise 8 V, 6.25 A 8 V, 12.5 A
Transient Response 8 V, from 3.125 A to 6.25 A 8V, from 6.25A to 12.5A
Current Programming & Readback, Zero Current 40 mA, 8 V 40 mA, 8 V
Current Programming & Readback, High Current 6.25 A, 8 V 12.5 A, 8 V
CC Load Effect, Source Effect 6.25 A, 8 V 12.5 A, 8 V
