Verification and Calibration Appendix B
Series N6700 User’s Guide 147
Test Record Form – Agilent N6733B and N6743B
Agilent N6733B and N6743B Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Constant Voltage Tests
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
+ 10 mV
Vout − 20 mV
19.96 V
Vout − 40 mV
__________
__________
__________
__________
+ 50 mV
Vout + 20 mV
20.04 V
Vout + 40 mV
CV Load Effect
Both
− 9 mV
__________ + 9 mV
CV Source Effect
Both
− 2 mV
__________ + 2 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
+ 14 mV
+ 3 mV
Transient Response
Voltage at 200 µs N6733B
N6743B
− 200 mV
− 300 mV
__________
__________
+ 200 mV
+ 300 mV
Constant Current Tests
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
Both
Both
N6733B
N6743B
N6733B
N6743B
− 10 mA
Iout − 5 mA
2.4762 A
4.9725 A
Iout − 8.75 mA
Iout − 12.5 mA
__________
__________
__________
__________
__________
__________
+ 30 mA
Iout + 5 mA
2.5237 A
5.0275 A
Iout + 8.75 mA
Iout + 12.5 mA
CC Load Effect
Both
− 2 mA
__________ + 2 mA
CC Source Effect
Both
− 1 mA
__________ + 1 mA
Instrument Settings
Test Description N6733B N6743B
Voltage Programming & Readback, Zero Voltage 30 mV, 2.5 A 30 mV, 5 A
Voltage Programming & Readback, High Voltage 20 V, 2.5 A 20 V, 5 A
CV Load Effect, Source Effect, Ripple and Noise 20 V, 2.5 A 20 V, 5 A
Transient Response 20 V, from 1.25 A to 2.5 A 20 V, from 2.5 A to 5 A
Current Programming & Readback, Zero Current 10 mA, 20 V 10 mA, 20 V
Current Programming & Readback, High Current 2.5 A, 20 V 5 A, 20 V
CC Load Effect, Source Effect 2.5 A, 20 V 5 A, 20 V
