PARTS LIST (C16)
NO. Parts Name Q'TY
1 POWER SUPPLY CABLE H07RNF 2.5 X 3C X3M UK Plug 1
1 POWER SUPPLY CABLE 1.5 x 3C x 3M - H07RNF(IP44) 1
1 POWER SUPPLY CABLE
SJTW 12AWG x3Cx3M- (TP-L503) 1
1 POWER SUPPLY CABLE
VDE 1.5 x 3C x 3M - H07RNF(IP44) 1
2 PRCD INTERRUPTER PROTECTION 220V 1
2 PRCD INTERRUPTER PROTECTION 220V 1
3 CORD ARMOR Ø15.5 1
3 CORD ARMOR Ø10.3 1
4 CABLE CLIP 1
5 PANHEAD TAPPING SCREW M4 x 14 3
6 TRIGGER SWITCH (LOCK-OFF) 1
7 N/A -
8 PANHEAD TAPPING SCREW M4 x 16 2
9 ELECTRONICS UNIT (110V) (220V) 1
10 PANHEAD TAPPING SCREW M4 x 8 4
11 BRUSH SPRING 2
12 CARBON BRUSH HOLDER 2
13 INSULATION PLATE 2
14 CARBON BRUSH 7 x 17 x 17 2
15 PANHEAD MACHINE SCREW M4 x 6 2
16 MOTOR HOUSING 1
17 HANDLE HALF-RIGHT 1
18 HANDLE HALF-LEFT 1
19 LED INDICATOR LIGHT 1
20 N/A -
21 CARBON CAP 2
22 PANHEAD TAPPING SCREW M4 x 12 2
23 PANHEAD TAPPING SCREW M4 x 25 6
24 PANHEAD TAPPING SCREW M4 x 50 6
25 GUIDE ROLLER ASSY. 1
26 STATOR (110V-100x54.1x75)(220V-100x54.1x75) 1
27 PANHEAD TAPPING SCREW M5 x 90 2
28 BALL BEARING 6200LLU 1
29 FAN SHROUD 1
30 ARMATURE (110V-100x54.1x75)(220V-100x54.1x75) 1
31 BALL BEARING 6202-2NSE 1
32 BEVEL PINION GEAR M2.35 x 6T 1
33 EXTERNAL STAR WASHER M4 1
34 WIRE LEAD 20AWG x 35cm 1
35A/B CRIMP CAP CONNECTOR A/C4 B/C5 1
36 GEAR HOUSING 1
37 SPRING WASHER M5 10
38 PANHEAD TAPPING SCREW-B M5 x 45 2
39 PANHEAD TAPPING SCREW-B M5 x 50 2
40 SPINDLE LOCK BUTTON 1
41 SPRING Ø0.9 x Ø7.4 x Ø9.2 x 5T x 16L 2
42 ARBOR LOCK 1
43 NEEDLE BEARING TA 1212 1
44 BEVEL GEAR M2.35 x 37T 1
45 SPINDLE 1
46 PARALLEL KEY 5 x 5 x 10 2
47 INTERNAL CIRCLIP R-62 1
48 BALL BEARING 6206-ZZ 1
49 GEAR PLATE 1
50 L-CLEVIS PIN 1
51 E-CLIP E-5 1
52 SOCKET CAP SCREW M5 x 25 4
53 OIL SEAL Ø25 x Ø35 x 5 1
NO. Parts Name Q'TY
54 FELT OILER Ø25 x Ø35 x 2.5 1
55 RUBBER FENDER Ø75 x Ø91 x 4 1
56 PLASTIC RING Ø74xØ91.5x0.25(mm) 1
57 UPPER BLADE COVER 1
58 DUST PORT BRACKET-LEFT 1
59 DUST PORT PLUG 1
60 FLAT WASHER Ø4 x Ø10 x 1 1
61 PANHEAD TAPPING SCREW-A M4 x 10 1
62 CLIP-FEMALE 1
63 BLADE GUARD BRUSH 1
64 DUST ATTACHMENT 1
65 DUST PORT BRACKET-RIGHT 1
66 SPLASH GUARD 1
67 TUBE 0.2M (Ø6.4 x Ø8.5) 1
68 WIRE HOSE CLAMP 1
69 FLAT HEAD TAPPING SCREW M4 x 16 6
70 WATER NOZZLE ASSY.-R 2
71 O-RING Ø4 x 1.5 3
72 WATER NOZZLE ASSY.-L 1
73 OUTER BLADE COVER 1
74 SOCKET CAP SCREW M4 x 12 7
75 CABLE PROTECTOR 5/16" x 75CM 1
76 WATER FEED CONNECTOR KIT 1
77 WATER COUPLING 1
78 FITTING 1
79 HOSE JOINER 3
80 ZIP TIE KTV-150BK 1
81 RETAINING PLATE Ø25.1 x Ø90 x 1.5 1
82 FLAT HEAD MACHINE SCREW M5 x 8 3
83 INNER FLANGE Ø25.4, Ø22.2 1
84 COUNTER FLANGE 1
85~87 N/A -
88 SOCKET CAP SCREW M8 x 16 2
89 FRONT HANDLE 1
90 COMBINATION WRENCH M17 1
91 SPRING 1
92 TOGGLE LATCH 3
93 PANHEAD MACHINE SCREW M4 x 6 6
94 TRUSS HEAD MACHINE SCREW M4 x 6 1
95 SOCKET HEX KEY M3 1
96 PANHEAD TAPPING SCREW M4 x 20 3
97 O-RING Ø35 x 1.5 1
98 BOLT M10 x P1.5 1
99A FLUSH CUT FLANGE SET 1
99A-1 FLANGE 1
99A-2 FLAT HEAD SOCKET CAP SCREW M8 x 16 6
99A-3 FLAT WASHER 1
99A-4 SOCKET CAP SCREW M10 x 25 1
99A-5 SOCKET HEX KEY M8 1
99A-6 SOCKET HEX KEY M5 1
99B FLUSH CUT FLANGE SET 60MM / 1" 1
99B-1 FLANGE 60MM / 1" 1
99B-2 FLAT HEAD SOCKET CAP SCREW M6 x 16 6
99B-3 FLAT WASHER 1
99B-4 SOCKET CAP SCREW M10 x 25 1
99B-5 SOCKET HEX KEY M8 1
99B-6 SOCKET HEX KEY M4 1
